• IMPORTANT: read these instructions carefully
and keep them for future reference.
Failure to follow these instructions could put the
childʼs safety at risk.
• PEG PEREGO reserves the right to make any
necessary changes or improvements to the products
shown at any time without notice.
Peg Perego S.p.A. is an ISO 9001 certified
company.
The fact that we are certified provides
a guarantee of our honesty for our
customers, and fosters trust in the
companyʼs way of working.
CUSTOMER SERVICE
If parts of the model are accidentally lost or damaged,
use only original Peg Perego spare parts. Contact
the Peg Perego Customer Service for all repair work,
replacements, information about products, and sale of
original spare parts and accessories, at the following:
tel.: 0039-039-60.88.213
fax: 0039-039-33.09.992
e-mail: [email protected],
www.pegperego.com
Peg Perego is at the consumer's service, meeting
every need in the best way possible. This is why our
customers' opinions are so important and valuable
to us. We would be very grateful if you would kindly
fill in the CUSTOMER SATISFACTION QUESTIONNAIRE
after using one of our products. You will find the
questionnaire on the Internet at "www.pegperego.
com/SSCo.html.en-UK".
Please note any observations or suggestions you may
have on the questionnaire.
INSTRUCTIONS FOR USE
OPENING THE STROLLER
1• To open the stroller, simultaneously press the two
buttons on the handlebar, and fix the handlebar
in the upright position. Unhook the catches, as
shown in the figure.
2• Firmly lift the handlebar upwards, then push
downwards until it clicks into place.
WHEEL ASSEMBLY
3• To mount the big wheels, align with proper
fittings and insert the wheels until you hear a
click.
MOUNTING THE BASKET
4• To mount the basket, press the side buttons and
pull to extract the basket rod.
5• Check that the basket bar is properly aligned as
indicated in the figure.
6• Slip the rod through the basket fabric. Insert the
rod with the basket into its housing, and press
until it clicks into place.
7• Fasten the basket sideways to the buttons and
before insert the two eyelets in the stroller as
indicated in the figure.
8• The stroller basket has three different positions.
A: The normal position.
B: A lowered position, obtained by pressing the
basket down, to allow you to use it even when the
backrest is completely lowered.
C: Basket raised to allow access to the rear
EN•ENGLISH
footrest.
BRAKE
9• To brake the stroller, push the brake levers on the
wheels downwards with your foot, as shown in the
figure. Always set the brake when the stroller is
not moving.
SAFETY BELT
10• A: Make sure that the brace is properly inserted by
pushing as shown in the figure. B: Fasten the belt
as shown in the figure.
11• To unfasten the belt, press on the buckle sides
and pull out the waist strap.
12• The new safety belt is now easier to fasten thanks
to the "snap-open-and-shut" device. Before
fastening the safety belt, attach the buckle to the
backrest by inserting the tab through the special
holder, as shown in the figure. After fastening
the safety belt on your child, detach it from the
backrest to allow the child more freedom of
movement. The buckle must remain below the
child's shoulders.
ADJUSTING THE BACKREST
13• The backrest reclines to three different positions.
To lower the backrest, lift the handlebar and fix
the backrest in the desired position. To raise the
backrest, pull it upwards.
ADJUSTING THE FOOTREST
14• The footrest can be adjusted to two positions.
To lower it, pull the two levers downwards while
lowering the footrest, as shown in the figure. To
raise the footrest, lift it upwards until it clicks into
place.
SWIVELLING WHEELS
15• The stroller is equipped with two smaller
swivelling wheels. To allow the wheels to swivel,
raise the lever as indicated in the figure. To lock
swivelling, lower the lever.
FRONT BAR
16• The front bar can be extended to two positions.
To extend it to the first position, pull the two
little levers under the front bar and the front bar
towards you, until you hear the first click. To
extend the front bar to the second position, pull
the two levers and the front bar towards you again
until you hear the second click.
17• When your children are bigger, you can remove
the front bar. To detach the bar, press the buttons
under the armrests, while pulling the front bar
out.
“CHILD TRAY”
18• To hook the child tray to the stroller, extend the
front bar to the second position and then hook the
tray onto it by pushing it down as shown in the
figure.
19• To remove the tray, push out the two side tabs of
the tray as you lift the tray upward. It is dangerous
to put hot drinks on the tray.
HANDLEBAR
20• To reverse the handlebar, simultaneously pull the
little levers on the handlebar upwards and move
the handlebar to the opposite position, pressing
until you hear the final click. While carrying out
this operation, be very careful not to catch your
child's hands or arms.
21• To adjust the handlebar height, press the side
buttons simultaneously, as shown in the figure,
and lock the handlebar into the desired position.
DRINK-HOLDER
22• The drink-holder attaches to both the right and
