THE PLAYER
1. POWER /STOP
2. EJECT( )
3. SETUP
4. PLAY/PAUSE ( / ) MODE
5. NEXT( )
6. PREV( )
7. / , / cursor buttons
(VOL+) / (VOL-)
8. OK
9. 7 inch TFT Color Monitor
10. Remote Sensor
11. Speakers
12. Disc tray
13. Data reading indicator
14. Button for compulsively ejecting
disc
15. DC 12V IN
16. Jack for earphone
17. AV IN
18. DIGITAL AUDIO
19. AV OUT
20. Reset button
21. Infrared transmitting area
(For the unit with infrared
transmitting function only)
