Specifications
PYD2200/2300U
Input Sensitivityllmpedance
MIG ..................................... 1.5 mV/600 Ohms Balanced
Phono 1-2 ........................... S.OmV/50K Ohms
Line .................................... 150 mV/27K Ohms
Output Level
Master ................................ 2.0 V/lOK Ohms
Booth ................................. 2.0 V/lOK Ohms
Record ................................ 150 mV/lOK Ohms
Frequency Response
....
20Hz - 20kHz +/- S dB
SIN Ratio (at 1 kHz)
Mic ..................................... 60 dBl1.5mV input
Phono ................................. 70 dBlS.OmV input
Line ..................................... 80 dBl150.0mV input
Distortion
Mic ...................................... 0.20%
Phono ................................. 0.05%
Line ..................................... O.OS%
Tone Control
Treble ............................... 10kHz; + 10/-1 OdB
Mid
.........................••......
1 KHz; +1O/-10dB
Bass ................................ 100Hz; +10/-10dB
MIC Tone Control
Hight ................................ 10 kHz; +10/-10dB
Low .................................. 100Hz; +10/-1OdB
Talkover Attenuation .. -16dB
Power Source
............
120 VAG,60Hzl2S0 VAG,50Hz
Dimensions, inches (mm)
WxHxD .......................... 19 x S x 7 (482 x 76.8 x 178)
Weight, Ibs (kg)
PYD2200 ............................ 8.44 (S.8S)
PYD2S00U .......................... 8.64 (S.92)
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement without notice.
Limited Warranty
All PYLE PRO products are carefully constructed and tested before shipment.
Units purchased In the USA are wa ranted to be free of defects In matenal
and workmanship for one (1) year from the date
of purchase. This warranty
Is limited to the original retail purchaser of the mixer.
Should the unit fail due to factory defects in material or workmanship. your
unit will be repaired or eplaced at the sole discretion of PYLE.
To obtain warranty service, you must first call our Consumer Return Hotline
at (718) 236-6948 to obtain a Return Authorization Number. This R.A. # must
appear on the outside of your package and on all paperwork relating to your
return.
When returning the unit to us for warranty service, It must be carefully
packed and shipped, prepaid, to:
..... Please complete warranty card, detach and return .....
R.A.#:
PYLE
1600 63rd Street
Brooklyn, NY 11204
You must also include the following items with your return:
• A copy of your sales receipt or other proof of purchase
• A brief letter, indi ca ting the problem you are experiendng with the product
• Include in your letteI" your return address, daytime phone number and R.A. number
• Also include a check or money order for $20.00 fOl" return
shipping, handling and insurance, or provide your Visa/N£. number with expiration date.
Our obligation under this warranty is limited to the repair or replacement
of the defect1ve unit when It Is returned to us prepaid. This warranty will
be considered vo1d If the unit was tampered with, Improperly serviced or
subject to misuse, neglect or accidental damage.
Thank you for purchasing this PYLE
product. To activate your
warranty, please mail this card
within 10 days.
warranty registration card
Name
Address
City, State ZIP
Model No.
Date of Purchase
Purchased at:
o
Music Products Store
o
Catalog Merchandiser
PYLE PRO MIXERS
Serial #
(If available)
o
Sound Contractor /Installer
O
Mail Order
o
Other
