Attach the speaker-cable stickers to make connection easier.
\Note]
≥Never short-circuit positive (i) and negative (j) speaker wires.
≥Be sure to connect only positive (copper) wires to positive (i) terminals and negative (silver) wires to negative (j) terminals.
Incorrect connection can damage the speakers.
STEP
3
Connecting speakers with the subwoofer
1 2 3 4 5
Sheet of speaker-cable stickers Speaker cable
≥4-m cable: For center speaker
SUBWOOFER
Insert the wire fully.
Speaker-cable sticker
2 FRONT (R)
1 FRONT (L)
4 SURROUND (R)
3 SURROUND (L)
5 CENTER
Copper
Silver
Click!
