Poulan Pro Rotary Lawn Mower PR625Y22SHP - Manual (Page 4)

4
1
2
2
3
5
6
7
9
11
9
11
12
12
13
13
14
14
15
15
16
16
18
18
28
35
36
38
38
40
41
ROT
AR
Y
LA
WN MOWER - - MODEL
NUMBER
PR625Y22SHP
(MFG. ID. NUMBER 96122002102)
5
1
194653
Drive Control Cable
Assembly
2
191039
Bearing, Wheel
Adjuster
3
143603
Pan Head T
apping Screw #10-24 x 2-3/4
5
146527
V
-Belt
6
150495
Spring Retainer
7
194185X421
Control Bar
, Drive
9
409148
Locknut, Hex
1
1
193912X421
Wheel & Tire
Assembly
12
12000058
E-Ring
13
403849
Pinion
14
189403
Dust Cover
15
404845
Pawl, Drive
16
67725
W
a
sher
18
701037X421
Selector Knob
28
194398X428
Drive Cover
35
424201
Kit, Wheel
Adjuster
, LH
(Includes Knob and Bearing)
36
415226
Gear Case
Assembly
, Complete
38
73800400
Locknut, Hex 1/4-20
40
137090
Spring
41
424200
Kit, Wheel
Adjuster
, RH
(Includes Knob and Bearing)
KEY
P
A
RT
NO.
NO.
DESCRIPTION
KEY
P
A
RT
NO.
NO.
DESCRIPTION
ROT
AR
Y
LA
WN MOWER - - MODEL
NUMBER
PR625Y22SHP
(MFG. ID. NUMBER 96122002102)
NOTE:
All component dimensions given in U.S. inches. 1 inch = 25.4 mm.
IMPORT
ANT
: Use only Original Equipment Manufacturer (O.E.M.) replacement
parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty
.
