REAR PANEL CONNECTIONS AND CONTROLS continued
Correct Speaker Polarity is Important
As you connect the speaker wires, you can see that the insulation on one of the two wires in
each pair has either printing or a raised ridge. The marking lets you know which wire you con-
nected to the positive speaker terminal at its other end.
Make sure the + wire you attach to each Model 2250 + speaker terminal is attached to the +
terminal of the speaker for that channel.
Bridging Switch: Stereo - Mono
The Model 2250 power should always be turned off before moving this switch.
For normal operation the Bridging switch must be set to Stereo.
For bridged mono operation, set it to Mono.
Note: Stereo sound will be faint and very distorted if you accidentally
leave the Bridging switch in its Mono position.
Mono Operation
For a mono speaker connection the Model 2250 “bridges” its R channel to amplify only the
positive half of the audio signal while its L channel amplifies only the negative half. In effect,
each amp channel “sees” only half of a mono speaker’s rated impedance, so that a single 8
ohm speaker in bridged mono is only a 4 ohm load; a single 4 ohm speaker in bridged mono is
only a 2 ohm load.
Note: You may safely connect one 4 ohm or two 8 ohm bridged mono speakers only if you set
the Load Impedance switch to its 2-3 ohm position.
Mono Input and Speaker Connections
1. Turn the unit off and remove the AC cord.
2. Connect the single cable from the preamp or controller to the R channel Input jack.
3. Set the Bridging switch to its Mono position.
4. Connect the positive lead of the speaker wire to the red R + channel speaker pair A terminal.
5. Connect the negative lead of the speaker wire to the red L + channel speaker pair A terminal.
6. Do not connect anything to either the L - or R - speaker terminals.
7. If you have a second 8 Ohm mono speaker, set the Load Impedance switch to the 2-3 Ohm
position and repeat steps 4-6 with the speaker pair B terminals.
8. Reconnect the AC cord.
Note: The Model 2250 creates more heat when it drives a bridged mono speaker or multiple
speaker pairs. Lower impedance speakers will make it run even hotter. Heat greatly reduces the
life of the amplifier and nearby components. Please heed the instructions for setting the Load
Impedance switch to avoid overheating.
Load Impedance Switch
