Using the menu
14 Philips Communication, Security & Imaging
English
D ISK MANAGER >
The disk manager menu gives access to information on the internal hard disk(s)
and any external disks connected. The status of the recorded video and associated
data is also accessed via this menu. Access to some menus is password protected.
>> STATUS OVERVIEW
• Disk capacity shows the total space available in Gigabytes.
• Used space shows the total space used by all video recordings including
protected recordings.
• Protect rec usage shows the space used by protected recordings that
cannot be overwritten.
• The displayed Recording time left value depends on the recording
options that are set, and alarm and motion frequency. The maximum
recording time shown depends on the available storage capacity and
recording setup.
>> PROTECTED RECORDINGS
(access may require password)
• Move to a protected recording in the list and press the select key to
play it back.
• Press the escape key to stop playback and return to the list.
To remove the protection of a recording, move to it in the list and press F2. You
must fill in a password (if configured) and confirm before the recording is
unprotected.
MAIN MENU
DISK MANAGER
STATUS OVERVIEW >
PROTECTED RECORDINGS >
AUTHENTICITY CHECK >
MAIN MENU
DISK MANAGER
STATUS OVERVIEW
EARLIEST RECORDING 2002-03-14 13:00:17
LATEST RECORDING 2002-06-19 20:23:45
DISK CAPACITY 50 GB
USED SPACE 30 GB
PROTECT REC USAGE 20%
RECORDING TIME LEFT 3 DAYS
MAIN MENU
DISK MANAGER
PROTECTED RECORDINGS
BEGIN TIME END TIME
2002-03-14 13:00:17 2002-03-14 14:30:17
