Page 2: Electrical, Dimensions
*Designs and specifications are subject to change without notice.
840 SERIES
MUL
TI-FUNCTION
TIMERS
840 SERIES
MULTI-FUNCTION
TIMERS
ELECTRICAL
MODEL
PLUG
PLUG
NUMBER DESCRIPTION
VOLT*
HZ.
WATTS
AMPS
NUMBER
CONFIG.
840-T4
4-Channel Timer
120
60
10 max
0.1
NEMA 5-15P
840-T8
8-Channel Timer
120
60
10 max
0.1
NEMA 5-15P
840-T16D
16-Channel Timer
120
60
25 max
0.2
NEMA 5-15P
SPECIFICATIONS
DIMENSIONS
MULTI-FUNCTION
NET
SHIPPING
MODEL
TIMER
HEIGHT
WIDTH
DEPTH
WEIGHT
WT.
NUMBER
CHANNELS
IN. (CM)
IN. (CM)
IN. (CM)
LB. (KG.)
LB. (KG.)
840-T4
4
5.38 (13.66)
9.31
(23.65)
1.59
(4.04)
4.5 (2.0)
6 (2.7)
840-T8
8
5.38 (13.66)
9.31
(23.65)
1.59
(4.04)
4.5 (2.0)
6 (2.7)
840-T16D
16 (dual display)
5.38
(13.66)
15.71
(39.91)
1.59
(4.04)
5.3 (2.4)
7 (3.2)
*Single phase.
5.38
(13.66)
9.31
(23.65)
1.59
(4.04)
A
B
C
A = 2.50" (6.35cm)
B = 2.05" (5.21cm)
C = 2.97" (7.54cm)
D
= 0.25" (0.635cm)
L = 10 feet (3.05m)
L
