8 Parker Hannifin Corporation
Open-Center Directional Control Valve
VO40
Catalog HY17-8505/UK
Inch equivalents for millimeter dimensions are shown in (**)
Mechanical Joystick
6.00
(0.236)
16.25
(0.640)
5.50
(0.216)
∅
4.80 (0.189)
62.0 (REF)
(2.44)
92.0
(3.62)
37.0
(1.46)
∅30.0
( 1.18) ∅
Dual Actuator
Pneumatic Actuator
16°
16°
16°
16°
20°
295
(11.6)
58
(2.3)
58
(2.3)
94
(3.7)
Float
43
(1.7)
102
(4.0)
137
(5.4)
Float
18
(0.7)
20°
Dimensions
Handle Rod
R1
140
20
M8x1
Ш7,3 Ш13 Ш11
42
30
R9
Ш7,35
