Parts and their functions
+CLP: Detail edge overshoot clip
This is used to limit the length of the overshoot parts of the
detail edge components.
–CLP: Detail edge undershoot clip
This is used to limit the length of the undershoot parts of
the detail edge components.
KNEE: Detail edge knee
This function applies the knee to the detail edge parts.
CRM: Chroma detail
This function boosts the detail in the high chroma
saturation.
CRSP: Chroma detail crisp
This is used to remove the very faint noise components
below the level set from the chroma detail components.
CRED: Chroma detail reduce
This is used to suppress the chroma detail edge.
SKIN_DTL: Skin tone detail
This is used to set the skin tone detail function to ON or
OFF.
SKIN_LVL: Skin tone detail level
This is used to set the chroma saturation of the parts
where the skin tone detail is applied.
ZEB: Skin tone area zebra
This is used to set whether or not to apply zebra to the
areas where coring is applied as the skin tones to the Y
signals in the PM output.
PHAS: Skin tone area phase
This is used to move the areas recognized as the skin
tones in the range of 153 to 93 along the Q axis on the
color vector display.
WIDTH: Skin tone area width
This is used to widen the areas recognized as the skin
tones in the range of 1 to 20 along the I axis on the color
vector display.
CRSP: Skin tone detail crisp
This is used to remove the very faint noise components
below the level set from the skin tone detail components.
> Matrix control switch [MATRIX CONTROL]
This is pressed to change the correction amounts for the
R-G, R-B, G-R, G-B, B-R and B-G chroma saturation.
R-G R-B G-R G-B
–10 0 +1 +10
B-R B-G
0 0
MTX 12 GAIN PHASE
Cy_B 0 0
MTX 12, GAIN, PHASE
These are used to select the following 12-axis matrix
adjustment items: G, G_Cy, Cy, Cy_B, B, B_Mg, Mg, Mg_R,
R, R_Ye, Ye and Ye_G.
GAIN
This is used to adjust the chroma saturation (gain) of the
items set using MTX 12 in the range of –127 to +127.
PHASE
This is used to adjust the phase of the items set using
MTX 12 in the range of –127 to +127.
? SYSTEM
HEAD, CCU OPT LEVEL:Camera, CCU light reception
strength level
These indicate the light reception strength margins of the
camera head and CCU.
RET1, RET2, RET3, RET4: Return video settings
These are used to set the input allocations of the return
signals.
DCMD: Down-conversion system selection
This is used to select the down-conversion system.
UCMD: Up-conversion system selection
This is used to select the up-conversion system.
HEAD OPT LEVEL πππππ
CCU OPT LEVEL πππππ
RET1 RET2 RET3 RET4
HDSDI1 HDSDI2 HDSDI3 HDSDI4
DCMD UCMD DCLK UCLK
SP SP ON ON
HBAR SBAR PATHO SET
ARIB SMPT OFF 7.5%
SDI4 MSEL MLINK
PM MIX ON
ANLG O_SEL SYNC TYPE
SD RGB ON TRI
H_CO HFIN (HDTV)
99 123
H_CO HFIN (SDTV)
99 123
SCCO SCFIN (SDTV)
7 30
SH_H SH_V
0 90H
VER
