6
1.
While a second person tips the Frame (2)
backward, attach a Wheel (25) to each side of
the Frame with an M10 X 35mm Shoulder Patch
Screw (94).
2. Carefully tip the Frame (2) onto its side. Orient
the Base (1) as shown, and then insert the Base
into the Frame. Attach the Base with two M10 x
62mm Patch Bolts (97), two M10 Spacers (76),
two M10 x 48mm Patch Screws (78), and two
M10 Split Washers (72).
Then, carefully tip the elliptical exerciser to an
upright position.
94
1
2
25
2
2
1
72
76
78
97
To make assembly easier, read the
information on page 5 before you begin.
