Philips PET716/93 - Manual (Page 16)

17
English
TECHNICAL DATA
Dimensions 210 x 178 x 39 mm
Weight 0.79 kg / 0.36 pounds
Power supply INPUT: 100-240V 50/60Hz 0.3A
OUTPUT: DC 9V 1A
Power Consumption 9W
Operating temperature range 0 - 45°C
Laser wavelength 650nm
Video system PAL
Frequency response 20Hz ~ 20KHz ± 1dB
Signal/noise ratio ≥ 80dB
Audio distortion + noise ≤ -80(1KHz)
Channel separation ≥ 80dB
Dynamic range ≥ 80dB
Audio out (analog audio) Output level: 2V ± 10%
Load impedance: 10KΩ
Video out Output level: 1Vp - p ± 20%
Load impedance: 75Ω
PHILIPS reserves the right to make design and specification
changes for product improvement without prior notice.
Modifications not authorized by the manufacturer may void users
authority to operate this device.
All rights reserved.
P1-17_PET716_93_Eng 1904.1.1 2:07 Page 17
