Philips PET718/55 - Manual (Page 35)

TECHNICAL DATA
Dimensions 203 x 40.4 x 149 mm
Weight 0.71 kg
Power supply DC 9V 2.0A
Power Consumption 18W
Operating temperature range 0 - 45°C
Laser wavelength 650nm
Video system PAL/NTSC
Frequency response 20Hz ~ 20KHz ± 1dB
Signal/noise ratio * 80dB
Audio distortion + noise ) -80(1KHz)
Channel separation * 80dB
Dynamic range * 80dB
Output
Audio out (analog audio)
Output level: 2V ± 10%
Load impedance: 10K1
Video out Output level: 1Vp - p ± 20%
Load impedance: 751
PHILIPS reserves the right to make design and specification
changes for product improvement without prior notice.
Modifications not authorized by the manufacturer may void users
authority to operate this device.
All rights reserved.
