■ On Screen Display (OSD) Functions in PC Mode (Analog)
Menu Function Setting Range
Basic menus
Auto adjust
Automatically adjust the image position, phase and
clock.
---
Brightness Adjust the brightness of image. 0~100
Contrast Adjust the contrast of image. 0~100
Phase*(1)
Adjust the image when there is noise or fuzzy
characters.
0~100
Clock (*1) Adjust the image when moire pattern appears. 0~100
Horizontal position
Vertical position
Adjust the image position. 0~100
Color
Color temperature
Adjust to give red or blue tone to white component
of the image; it may be done before printing or photo
retouch.
User/5700/
6500/9300/sRGB
Red (*2) Adjust the red color of image.
Green (*2) Adjust the green color of image.
Blue (*2) Adjust the blue color of image.
0~100
Sound
Volume
Adjust speaker volume. 0~100
Treble Adjust the high frequency audio. -50~+50
Bass Adjust the low frequency audio. -50~+50
Balance Adjust the balance of left and right sound track. L~R
Mute Eliminate the sound. NO/YES
PC/PIP Select the PC sound or PIP sound. PC/PIP
Others
OSD language (*3) Select the display language.
Japanese/English
OSD horizontal
position
OSD vertical
position
Adjust the display position of OSD window. 0~100
Smoothing Choose whether to activate the smoothing function. NO/YES
Zoom To magnify the image. NO/YES
Selection of WXGA
and XGA Used when image display is abnormal during
resolution switch. Auto adjust in case of digital input.
Auto
Reset Return to the factory default settings. ---
PIP
PIP OFF/ON
Select the OFF/ON of PIP window. OFF/ON
PIP size Select the size of PIP window. 0~100
PIP horizontal
position
PIP vertical position
Change the PIP window position. 0~100
PIP source Select the PIP video source. TV/SVideo/Video1/Video2
