Select Traveller www.pridemobility.com 17
I I I . Y O U R P O W E R C H A I R
THE SELECT TRAVELLER
The Select Traveller has two main assemblies: the seat assembly and the power base assembly. See figure 5.
Typically, the seat assembly includes the armrests, seatback, and seat base. The power base assembly includes the
two motors, two drive wheels, two caster wheels, two anti-tip wheels, two batteries, and a foot platform. See
figures 5 and 6.
SEATBACK
Figure 5. The Select Traveller
JOYSTICK
ARMRESTS
DRIVE WHEEL
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
FRONT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
CONTROLLER
CASTER WHEEL
