- 41 - PIN ASSIGNMENTS

RS232 SIGNAL OUTPUT
COLOR

FUNCTION

9 PIN DSUB/AMP (F) 25 PIN DSUB (F)

BROW GND

5

7

YELLO

CTS

8

4

GREEN RTS

7

5

ORANGE RX

2

2

BLUE TX

3

3

PURPLE Vcc

+5V

9

25,16
