PowerBass Xtreme XL - Manual (Page 3)

Subwoofer
Custom CNC Cast Aluminum Basket heavy duty design incorporating motor assembly cooling vents
Proprietary Non-pressed Paper Cone Body With Xpanded Zirconium Coated Poly Truss
is every thing that you need to produce the deepest and loudest bass known to man
Dual 1-ohm Voice Coils specifically built to handle all of your Class D needs
3" HD BASV Hybrid Voice Coil Formers for optimum performance and cooling
Industrial Assembly Glues are used to handle the Extreme heat that a Class D amplifier produces that
would normally annihilate a common subwoofer
CNC Billet Aluminum Trim Ring clamps surround to basket for increased durability
Ultra High Roll Treated Foam Surround that increases the cone area for higher output along with
linear cone stability throughout the subwoofers 3 inches of linear travel
XTRA XTRA XTRA Large Motor Assemblies to handle the high voltage input into these beasts
Pro-lock Input Terminals to ensure optimal current transfer from the amplifier to the woofer
The 3XL range of subwoofers is innovative
in that it is designed to work with the new
generation Class "D" amplifiers. Class "D"
amplifiers heat up the woofers voice coil
two to three times hotter and faster than a
conventional class A/B amplifier. This calls
for Xtreme measures and special parts to
classify these as a true "Class D Subwoofer."
But hey, this is PowerBass. We have it
under control.
First, we use industrial assembly glues that
handle this excessive heat that would
normally tear a conventional speaker apart.
Then there is perimeter venting to allow air
movement over the voice coil built into our
custom CNC cut, cast aluminum basket.
The basket works as a strong support for the
moving mass of the proprietary non-pressed
paper cone body that holds the zirconium-
coated poly truss cone that displays the
raised PBX logo.
The 3XL woofers all feature 3" HD BASV
voice coil formers that are anodized black to
help dissipate heat. To allow full movement
of the cone, we utilize an ultra high roll
treated foam surround that increases the
cone area for higher output along with
linear cone stability throughout the
subwoofers 3" of linear travel.
To make sure high voltages from the
amplifier reach the speaker, we use
Pro-Lock terminals and Xtra large motor
assemblies to handle the high power these
speakers are designed for.
3XL woofers are available in 10", 12", and
15" sizes, feature dual 1-ohm voice coils,
and are designed to work best in ported
enclosures for maximum SPL output.
3XL
3XL
series
mounting
depth
size frequency
response
nominal
impedance
sensitivity
(1w / 1m)
voice
coil size
motor
structure
3XL-15D 9.2" 15" 24Hz-400Hz Dual 1-ohm 93 dB 3" 542 oz 1000 / 2000 watts
3XL-12D 7.75" 12" 31Hz-450Hz Dual 1-ohm 91 dB 3" 542 oz 850/ 1700watts
3XL-10D 6.0" 10" 39Hz-500Hz Dual 1-ohm 89 dB 3" 443 oz 750/ 1500watts
power handling
(rms/peak)
1o”, 12”, 15”
Class D subwoofer
FOR MAXIMUM SPL OUTPUT
ENCLOSURES
D E S I G N E D F O R
PORTED
04 05
