- 30 -
Specifications
TFT Screen Size 8 inches
Laser Wavelength Wavelength: 780/650nm
Video System NTSC
Frequency Response 20Hz～20KHz ±2.5dB
Audio Signal-To-Noise Rate ≥ 80 dB
Audio Distortion + Noise ≤ -70dB (1KHz)
Channel Separation ≥ 70dB (1KHz)
Dynamic Range ≥ 80dB (1KHz)
Audio Out
Analog Audio
O
Out Level: 1.5V±
0.2
1.0
, Load: 10KΩ
Video Out Video Out
Out Level: 1V
P-P
±0.1, Load: 75Ω
Unbalanced Negative
Power AC100～240V, 50/60Hz
Power Consumption ＜ 13W
Dimension w/o Battery 214mm×158mm×52/40mm (L/W/H)
Weight w/o Battery About 1.0/0.68kg
Compliance with FCC, FDA - cUL listed E209155
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.
©
1992 -1997 Dolby Laboratories.
All rights reserved.
