ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION
MISCELLANEOUS
CF201 1012T6R014 FILTER,CERAMIC TRAP TPSRA6M00B00-A0
CF202 102E239R5B FILTER SAW J1951M
CF204 1012T04101 FILTER,CERAMIC TRAP MKT41.5MA110P
CP001 069W01001A CONNECTOR PCB SIDE 003P-2100
CP101 069X160379 CONNECTOR PCB SIDE 06JQ-ST
CP401 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P
CP502 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
CP801 069W01001A CONNECTOR PCB SIDE 003P-2100
CP1001 069W120019 CONNECTOR PCB SIDE TID-X02P-B2
CP802A 067U006049 WIRE HOLDER B2013H02-6P
CP802B 067U006049 WIRE HOLDER B2013H02-6P
CP803A 067U004029 WIRE HOLDER B2013H02-4P
CP803B 067U004029 WIRE HOLDER B2013H02-4P
EL002 124120301A EYE LET XRY20X30BD
! F501 080NT04004 FUSE 50T040H
! FB401 043214039F TRANSFORMER,FLYBACK FNI-14B002
FH501 06710T0006 HOLDER,FUSE EYF-52BC
FH502 06710T0006 HOLDER,FUSE EYF-52BC
OS101 0773071001 REMOTE RECEIVER RPM7138-H5
SP1001 070C132019 SPEAKER SA08A05BWC
! TH501 D8E080B100 DEGAUSS ELEMENT B59104-T80-B10
TM101 076N0GE030 TRANSMITTER RC-GE030
TU001 0144R07025 TUNER,UHF UE25-B58D
! V801 098Y1404B9 CRT W/DY A34JXV70X53N45
X101 100CT4R013 CRYSTAL HC-49/U-S
X601 100CT4R408 CRYSTAL HC-49/U
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP.................. POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP................... METAL POLYESTER CAPACITOR
CMPL................ METAL PLASTIC CAPACITOR
CMPP................ METAL POLYPROPYLENE CAPACITOR
J2-2
