107S66/93
Technical specifications Product highlights
CRT monitor
17" real flat XGA
Date of issue 2006-07-07
Version: 3.0
12 NC: 8639 000 15594
EAN: 87 10895 85345 3
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2006 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
Picture/Display
• Display screen type: Real Flat picture tube
• Panel Size: 17"/ 41 cm
• Phosphor: P22
• Recommended display area(mm): 306 x 230 mm
• Recommended Display Area(inch): 12" x 9"
• Dot pitch: 0.25 mm
• Dot Pitch (horizontal): 0.21 mm
• White Chromaticity, 6500K: x = 0.313 /
y = 0.329
• White Chromaticity, 9300K: x = 0.283 /
y = 0.297
• Maximum Resolution: 1280 x 1024 @ 60 Hz
• Recommended Resolution: 1024 x 768 @ 85 Hz
• Factory Preset Modes: 8 modes
• Factory Preset Mode: 640 x 480 @ 60 Hz, 640 x
480 @ 85Hz, 720 x 400 @ 70 Hz, 800 x
600 @ 75 Hz, 800 x 600 @ 85 Hz, 1024 x
768 @ 75 Hz, 1024 x 768 @ 85 Hz, 1280 x
1024 @ 60 Hz
• Factory Preload Modes: 14 modes
• Video Dot Rate: 120 MHz
• Horizontal Scanning Frequency: 30 - 71 kHz
• Vertical Scanning Frequency: 50 - 160 Hz
• Recommended Refresh Rate: 85 Hz
• Screen enhancement: Anti-glare Polarizer, Anti-
Reflection, Anti-Static, High Brightness, High
Contrast
• Digital deflection
• sRGB
• GTF
Connectivity
• Cables: D-sub Video Cable, Power Cord
• Sync input impedance: 4.7k ohm
• Video input impedance: 75 ohm
• Video input signal levels: 0.7 Vpp
• Video Sync Input Signal: Separate Sync
• Video Sync Polarities: Positive and Negative
• Cable Connection: AC Power in
Convenience
• Convenience Enhancements: Menu Languages,
On-screen Display
• Monitor Controls: Bright Direct Access,
Contrast Direct Access, High Bright Hotkey,
Menu, Power On/Off
• OSD Languages: English, French, German, Italian,
Spanish, Portuguese, Korean, Simplified Chinese
• Plug & Play Compatibility: DDC 2B, Windows
98/ME/2000/XP
• Regulatory Approvals: CE Mark, FCC-B, UL,
CSA, MPR-II, Low Emission, NUTEK, Energy
Star, SEMKO, TÜV/GS, TÜV Ergo, FDA, EZU,
GOST, MEEI, PCBC, CCC, BSMI, E2000
• Swivel: +/- 90°
• Tilt: -5° to 13°
Accessories
• Included Accessories: AC Power Cord
• Optional accessories: Multi-media base
• User Manual
Dimensions
• Dimensions (with base) (W x H x D):
397 x 383 x 424 mm
• Temperature range (operation): 0°C to 40°C
• Temperature range (storage): -25°C to 65°C
• Weight: 15 kg
Power
• Complies with: Energy Star, NUTEK, E2000
• Consumption: 68 W (Typical)
• Off Mode: 1 W
• Power LED indicator: Off - Flashing Green,
Operation - green
• Power supply: Built-in
•
Digital Deflection CPU
An exclusive Philips innovation -- the world's first one-
chip CRT solution -- combines the deflection and the
Microcontroller in a single chip to process and control
input sync digitally. This innovative technology prevents
electronic noise that can harm display quality, reduces
display jitter and improves geometry for better front of
screen performance.
High Bright Hot Key
A feature that delivers instant brightness adjustment to
the ideal level for viewing text, Internet, game or
multimedia applications, providing comfortable viewing
and an enhanced experience for each type of
application.
XGA, 1024 x 768 resolution
For graphics monitors, the screen resolution signifies the
number of dots (pixels) on the entire screen. For
example, a 1024-by-768 pixel screen is capable of
displaying 1024 distinct dots on each of 768 lines, or
about 786 thousand pixels. XGA provides resolutions of
640 by 480 or 1024 by 768 pixels.
High-bright-high-contrast tube
A CRT tube designed to increase display brightness and
contrast by increasing the CRT ray gun's beam current.
Real flat CRT display
Philips advanced flat CRT technology reduces glare and
reflection more efficiently than a conventional CRT. The
special high-bright, high-contrast shadow mask helps
maintain sharper focus and eliminates 'color blooming'
compared to standard tubes. It displays images on a
monitor that look like images on paper: Viewing the
image is more comfortable. Straight lines are straight.
Finding a reflection-free viewing position is much easier.
This adds up to reduced eyestrain for a comfortable
viewing experience.
sRGB ready
Calibrated RGB that is optimized for the vast majority
of computer peripherals, monitors, operating systems
and browsers, allowing accurate color mapping with
very little data overhead.
Two-platform compatibility
The ability to work with a variety of platforms; Philips
monitors are compatible to connect with PC by
employing a VGA connection and connect with
Macintosh.
Lead-free
Lead-free display products are designed and produced
in compliance with strict European Community
Restriction of Hazardous Substances (RoHS) standards
that restrict lead and other toxic substances that can
harm the environment.
Energy efficiency
Reduction of the electrical power required to operate a
device to achieve real savings.
MPRII compliant
The world standard setting stringent levels for
electromagnetic radiation emitted by monitors.
Energy Star partner
A manufacturer in compliance with power conservation
requirements set forth by the Environmental Protection
Agency of the U.S. government.
Flame retardant case
PC/ABS plastic composite is the industry-best tough,
flame-retardant casing material, a space-age
compound deployed in the aerospace and automotive
industries as well as in fire detectors.
