Panasonic DMC-G3K - Manual (Page 48)

VQT3N40 (ENG)
48
Interchangeable Lens (H-FS045200)
“LUMIX G VARIO 45 – 200 mm/F4.0 – 5.6/MEGA O.I.S.”
Focal length f=45 mm to 200 mm
(35 mm film camera equivalent: 90 mm to 400 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Aperture range F4.0 (Wide) to F5.6 (Tele)
Minimum aperture
value F22
Lens construction 16 elements in 13 groups (no aspherical lens)
In focus distance 1.0 m (3.28 feet) to ¶ (from the focus distance reference line)
Maximum image
magnification 0.19 k (35 mm film camera equivalent: 0.38k)
Optical Image
Stabilizer Available
[O.I.S.] switch Available (Switching ON/OFF)
Mount “Micro Four Thirds Mount”
Angle of view 27 x (Wide) to 6.2x (Tele)
Filter diameter 52 mm (2.05 inch)
Max. diameter Approx. 70 mm (2.76 inch)
Overall length Approx. 100 mm (3.94 inch)
(from the tip of the lens to the base side of the lens mount)
Mass (weight) Approx. 380 g/0.84 lb
