26
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
01.05.004-B
1
2
4
4
4
4
3
REPAIR PARTS SNOW THROWER - - MODEL NUMBER XT8527ES (96192002302)
HANDLES
1
2
3
3
4 4
3
3
01.08.004-B
4
4 1 419798X479 LOOP HANDLE LH
2 419799X479 LOOP HANDLE RH
3 74780524 SCREW 5/16−18 X 1.50
4 751153 NUT 5/16−18
1 419797X479 LOWER TUBE
2 418313X479 PIVOT SUPPORT
3 150078 BOLT 5/16−18 X .750
4 17000616 SCREW 3/8−16 X 1.00
