English
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers, register
your product at www.philips.com/welcome.
Controls (see 1)
1 2
– switches the system on or to standby mode.
2 Display
– shows clock/alarm time and status of the set.
3 TIMER – activates/deactivates the timer.
FM/MW – selects the waveband: FM or MW.
SET TIMER – sets the timer.
4 LIGHT
– adjusts the brightness of the display.
5 TUNING
– tunes to radio stations.
6 VOL F
– adjusts the sound level.
7 Battery compartment
8 ;
– 3.5 mm stereo headphone socket.
9 SET TIME – sets the clock time.
HOUR – adjusts the hour for the clock/alarm time.
MIN – adjusts the minutes for the clock/alarm time.
0 Telescopic antenna
– improves FM reception.
POWER SUPPLY
Batteries (not included)
Open the battery door and insert two alkaline batteries, type
AA, R06 or
UM3 , as indicated in the battery compartment.
• Incorrect use of batteries can cause electrolyte leakage and will corrode
the compartment or cause the batteries to burst.
• Do not mix battery types: e.g. alkaline with carbon zinc. Only use batter-
ies of the same type for the set.
• When inserting new batteries, do not try to mix old batteries with the
new ones.
• Remove the batteries if the set is not to be used for a long time.
Batteries contain chemical substances, so they should be disposed
of properly.
This set complies with the radio interference requirements of the
European Union.
General information
Antennas
• For FM, extend, incline and turn the telescopic antenna for best recep-
tion. Reduce its length if the signal is too strong.
• For MW, the set uses a built-in antenna. Direct this antenna for best
reception by turning the whole set.
Connecting headphones
• You can connect headphones to the headphone socket.
➜ The loudspeakers will then be switched off.
RADIO RECEPTION
1 Press 2 to switch on the radio.
2 Press FM/MW to select your desired waveband.
3 Select your station using the TUNING control.
4 Adjust the sound with the VOL F control.
5 To switch off the radio, press 2.
Setting the clock/timer
1 In standby mode, hold down SET TIME / SET TIMER.
2 Press HOUR or MIN repeatedly, or hold down HOUR or MIN to
adjust minute and/or hour.
3 Release SET TIME / SET TIMER and HOUR or MIN when you
reach the correct setting.
➜
The set clock time will show on the display and start to run.
Activating/deactivating the timer
• Press TIMER once or more to activate/deactivate the timer.
➜ The radio will automatically switch on at the set time after the timer is
activated.
Adjusting the brightness of the display
• To change the brightness of the display, press LIGHT.
SAFETY & MAINTENANCE
• Do not expose the set, batteries to humidity, rain, sand or excessive
heat caused by heating equipment or direct sunlight.
• The apparatus shall not be exposed to dripping or splashing.
• To clean the set, use a dry cloth. Do not use any cleaning agents con-
taining alcohol, ammonia, benzene or abrasives as these may harm the
housing.
• Battery shall not be exposed to excessive heat such as sunshine, fire or
the like.
Troubleshooting
If a fault occurs, first check the points listed below before taking the set
for repair.
If you are unable to remedy a problem by following these hints, consult
your dealer or service centre.
WARNING: Do not open the set as there is a risk of electric shock. Under
no circumstances should you try to repair the set yourself, as this will invalidate
the guarantee.
Problem
– Possible cause
• Remedy
No sound /power
– Volume not adjusted
• Adjust the VOLUME.
– Batteries dead/ incorrectly inserted
• Insert (fresh) batteries correctly
– Headphones connected to the set
• Disconnect headphones.
Poor radio reception
– Weak radio signal
• For FM, extend, incline and turn the telescopic antenna for best recep-
tion. Reduce its length if the signal is too strong.
• For MW, the set uses a built-in antenna. Direct this antenna for best
reception by turning the whole set.
