©2009 Philips
Made in China

www.philips.com

Limited One-Year Warranty
Philips warrants that this product shall be free from defects in material, workmanship and assembly, under normal use, in accordance with

the specifications and warnings, for one year from the date of your purchase of this product. This warranty extends only to the original

purchaser of the product, and is not transferable. To exercise your rights under this warranty, you must provide proof of purchase in the

form of an original sales receipt that shows the product name and the date of purchase. For customer support or to obtain warranty

service, please call 1-919-573-7854. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES. Philips’ liability is limited to repair or,

at its sole option, replacement of the product. Incidental, special and consequential damages are disclaimed where permitted by law. This

warranty gives you specific legal rights. You may also have other rights that vary from state to state.

Función:

Permite la sustitución de la tapa de una caja

de pared existente o la instalación en superficie

para un nuevo teléfono de pared, modem o

internet.

Herramientas Necesarias: Destornillador,

cable de teléfono, alicate para cortar cable,

separador de cables, grapas para cable.

Red (Rojo)

Standard

A

B

C

Green (Verde)
Yellow (Amarillo)
Black (Negro)
Blue (Azul)
White (Blanco)

Blue/White Band (Azul/Blanco Raya)
White/Blue Band (Blanco/Azul Raya)
Orange/White Band (Naranja/Blanco Raya)
White/Orange Band (Blanco/Naranja Raya)
Green/White Band (Verde/Blanco Raya)
White/Green Band (Blanco/Verde Raya)

Blue/White Band (Azul/Blanco Raya)
White/Blue Band (Blanco/Azul Raya)
Orange/White Band (Naranja/Blanco Raya)
White/Orange Band (Blanco/Naranja Raya)

Blue (Azul)
White/Blue Band (Blanco/Azul Raya)
Orange (Naranja)
White/Orange Band (Blanco/Naranja Raya)

Use this chart if existing wires are different from Standard Red, Green (Line 1), Yellow, Black (Line 2), Blue, White (Line 3):

Utilice la carta si los cables existentes difieren de los estándar Rojo, Verde (Línea 1), Amarillo, Negro (Línea 2), Azul, Blanco (Línea 3):

*Wiring Color Cross Reference Chart (*Carta de Cableado con Referencia Cruzada de Colores)

Function:

Allows for replacement of existing wall box

cover or surface-mount for new installation of

wall phone, modem or internet.

Tools Needed: Screwdriver, Phone Wire,

Wire Cutters, Wire Strippers, Wire Clips.

RJ45

RJ12

6 conductor supports up to 3 separate lines.

El conductor de 6 hilos soporta hasta 3 líneas independientes.

WALL JACK

Modular outlet for phone, modem

or internet connections

Salida modular para cualquier conexión de línea de teléfono,

modem o internet

6 & 8

conductor / conductores

SDJ8040W/17

RJ12

RJ45

SDJ8040W/17

White/Blanco
