6
WIRING CONNECTION
ANTENNA CONNECTOR
(BLACK)
CD CHANGER
CONNECTOR SOCKET
(BLACK)
FUSE
WIRING REMOTE
CONNECTOR SOCKET
AUDIO R IN (RED)
AUDIO L IN (WHITE)
XM RECEIVER CONNECTOR SOCKET (BLACK)
RED RCH
WHITE RCH
AUX IN CABLE (YELLOW)
XM AUDIO CABLE(BLACK)
RED
WHITE
Rch
Lch
FRONT RCA CABLE (BROWN)
RED
Rch
Lch
REAR RCA CABLE (GREY)
BLUE
RED
YELLOW
BLACK
POWER ANTENNA
IGNITION SWITCH (ACC+)
MEMORY/BATTERY (B+)
GROUND (B-)
FRONT Lch
SPEAKER
REAR Lch
SPEAKER
GREEN
GREEN/BLACK
WHITE
WHITE/BLACK
VIOLET
VIOLET/BLACK
GREY
GREY/BLACK
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
WHITE
