INSTALLATION
EATON Powerware
®
BladeUPS
®
EBM User's Guide
S 164201650 Rev 2 www.powerware.com
20
13. Verify that the brackets are seated firmly, then tighten the wing
nuts on the rear hold-down brackets. The EBM is now secured in
the rack.
14. If installing additional EBMs, repeat Steps 7 through 13 for each
cabinet.
15. Continue to the following section “EBM Installation.”
EBM Installation
C A U T I O N
A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and
will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and
firmly.
To install the EBM(s) for a UPS:
1.
Verify that all battery circuit breakers are in the OFF (O) position
(see Figure 9).
2.
Plug the EBM cable(s) into the battery connector(s) as shown in
Figure 9. Up to four EBMs may be connected to the UPS.
NOTE The batteries charge to 80% capacity in less than 5 hours. However, it is
recommended that the batteries charge for 48 hours after installation or long-term storage.
