BDL4211VS/00 LCD monitor
42" WXGA
Specifications Product highlights
Picture/Display
• LCD panel type: 1366 x 768 pixels, Anti-glare
polarizer
• Panel Size: 42" / 106.7cm
• Pixel pitch: 0.6810 x 0.6810 mm
• Brightness (nits): 600 nit
• Contrast ratio (typical): 600:1
• Display colors: 16.7 Million colors
• Viewing angle: @ C/R > 10
• Viewing angle (H / V): 176 / 176 degree
• Response time (typical): 12 ms
• White Chromaticity, 9300K: x = 0.283 / y = 0.297
• White Chromaticity, 6500K: x = 0.313 / y = 0.329
• Maximum Resolution: 1366 x 768 @ 60Hz
• Recommended Resolution: 1366 x 768 @ 60Hz
• Factory Preset Modes: 10 modes
• Horizontal Scanning Frequency: 31 - 49 kHz
• Refresh Rate (V): 60Hz
• sRGB
• Picture enhancement: Picture in Picture,
Progressive Scan
• Aspect ratio: 16:9
Supported Display Resolution
Connectivity
• PC: VGA-in D-Sub 15HD, DVI-D x1, 3.5 mm PC
audio input x1, RS232 D-Sub9
• AV input: Composite (CVBS) x1, S-video x1,
Component (YPbPr) x1, SCART x1, Audio (L/R)
for YPbPr x1, Audio (L/R) x1
• Audio output: Speaker Out 2x mini-jack 3.5mm,
Stereo Audio (3.5 mm jack) 1x
Convenience
• Convenience Enhancements: On-screen Display
• Monitor Controls: Left/Right, Menu (OK), Power
On/Off, Source Select, Up/Down, Brightness
Control, Contrast Control, Video select
• OSD Languages: English, French, German, Italian,
Spanish, Simplified Chinese
• Plug & Play Compatibility: sRGB, Windows 98/ME/
2000/XP
• Regulatory Approvals: CE Mark, FCC-B, UL, CSA
Power
• Consumption: 180W
• Sleep Mode: <2W
• Power LED indicator: Operation - Blue, Stand by/
sleep - Amber
• Power supply: Built-in
Dimensions
• Dimensions (without base) (W x H x D):
1035 x 626 x 115 mm
• Weight: 29 kg
• MTBF: 50,000 (excl. CCFL 60,000) hrs
• Temperature range (operation): 5°C to 40°C
• Temperature range (storage): -20°C to 60°C
• Relative humidity: 20% - 80%
Accessories
• Included Accessories: AC Power Cord, Remote
Control, VGA cable, DVI-D cable, Battery
• User Guide on CD-ROM
• Optional accessories: Fixed wall mount, Flexible
wall mount, Ceiling mount
Miscellaneous
• Warranty: 3-year on site
• Bezel: silver
•
• Video formats
Resolution Refresh rate
480i 60Hz
480p 60Hz
576i 50Hz
576p 50Hz
720p 60Hz
1080i 60Hz
• Computer formats
Resolution Refresh rate
800 x 600 60Hz
640 x 480 60Hz
1280 x 768 60Hz
1024 x 768 60Hz
1366 x 768 60Hz
Issue date 2008-06-16
Version: 2.0.3
12 NC: 8639 000 16498
EAN: 87 10895 91415 4
© 2008 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Network controllability: RS232
Network controllability allows user to control and adjust
monitors remotely through RS232 protocol.
VGA loop through
In case more than one screen need to share the same
input signal, VGA loop through offers a cost effective
solution in which the VGA input signal is amplified and
made available on a VGA output connector which can be
connected to the next monitor
Fanless operation in landscape
In landscape mode the monitor operates without
activating fans. To make the monitor even more flexible
in use one can mount this product also in portrait mode.
Circomstances in this mode might require additional
cooling. A thermal sensor will then activate cooling fans.
Portrait mounting possible
This display is also able to be safely and reliably mounted
in portrait position.
WXGA 1366x768 resolution
Automatic brightness control
The adjustment of display settings to correspond with
ambient light without user intervention.
DCDi de-interlacing
DCDi enhances the quality of all images by eliminating
the stair-step jagged edges so often seen on progressive
scan displays resulting in natural images with exceptional
detail.
Picture In Picture (PIP)
Provides the ability to watch simultaneously two different
sources, either two video sources or a combination with
data/graphics
No permanent burn-in
Public displays often show static information which could
cause ghost images (burn-in). By simply switching off/on
the monitor these ghost images disappear fully.
Robust metal bezel
Specially designed for demanding public applications, the
metal bezel offers higher durability and protection
against vandalism. Annodized paint is used to offer extra
protection of the bezel against scratches.
Intelligent power management
Intelligent power management employs energy-efficient
technologies in product design to reduce power
consumption and significantly lower the total cost of
ownership.
Hidden control buttons
Control buttons placed at the rear of a monitor used for
public display to prevent tampering with display settings.
