11
Power Supply: 120 V, AC 60 Hz
Power Consumption: Approx. 4 W
Data Input/Output: 6-conductor Modular Jack (RS-485, 4-wire)
Switching Functions: Program Sequence/Tour Sequence
Group Sequence/Backward Sequence
Forward Sequence/Inc Dec
Camera Functions: Electronic Shutter: On/Off, Shutter Speed Select
Electronic Sensitivity Up Mode Select: Auto/Manual/Off
Electronic Zoom: On/Off, Zoom Position: Area Select
Back Light Compensation: Auto/Preset/Off
Lens Functions: Iris: Open/Close/Preset (only with DC control lens)
Focus: Near/Far
Zoom: Tele/Wide
Auto Focus: Activate
Housing: Wiper: On/Off, Defroster: On/Off, Camera: On/Off
Pan/Tilt: Manual Pan: Right/Left, Manual Tilt: Up/Down
Auto Pan: On/off, Random Pan: On/Off, Preset, Home
Auxiliary Switch: AUX 1-2: On/Off
Unit Number: 1 - 8
Ambient Operating Temperature: –10°C - +50°C (14°F - 122°F)
Ambient Operating Humidity: Less than 90 %
Dimensions: 330 mm (W) x 74 mm (H) x 221 mm (D)
13” (W) x 2-15/16” (H) x 8-11/16” (D)
Weight: 2.2 k g (4.8 lbs.)
Weight and dimensions indicated are approximate.
Specifications are subject to change without notice.
SPECIFICATIONS
Data Cable 3 m (9.8 ft.) ................................................................. 1 pc.
Templates For WJ-FS616.................................................................1 set
STANDARD ACCESSORY
Matrix Switcher .......................................... WJ-SX550C
Extension Unit ............................................ WJ-AD550
Video Input Board ..................................... WV-PB5508
Video Output Board ................................... WV-PB5504A
Alarm Board .............................................. WV-PB5564
Data Board ................................................ WV-PB5548
Rack Mounting Bracket ............................. WV-Q62
Blank Panel ................................................ WV-Q63
MAJOR OPTIONAL UNITS AND ACCESSORIES
