SPECIFICATION
22
GENERAL
SIGNAL SYSTEM
DISCS PLAYED
AUDIO SIGNAL OUTPUT :
CHARACTERISTICS
Supply Voltage :12v Dc (11v-15v)
Current Consumption More Then 10 A
:Compositive Video 1.0vp-p 75
(1)Dvd-video Disc
5"(12 Cm) Single-sided, Single-layer
5"(12 Cm) Single-sided, Double-layer
(2)Compact Disc (cd-da, Video Cd)
5"(12cm) Disc
2ch&4ch Line Out
(1)Frequency Response 20 Hz - 20 Khz
(2)S/n Ratio 90 Db (jis)
(3)Wow And Flutter
Below Measurable Limits
:
RADIO
FM TUNER SECTION
AM TUNER SECTION
Tuning Range :87.5-107.9MHz
IF Range :10.7MHz
Usable sensitivity(30dB) :15dB
Frequency Range :530-1710KHz
IF Range :450KHz
Usable sensitivity(30dB) :45dB
TV TUNER
TV System :NTSC or PAL
TV Sensitivity :
NOTE:
Specifications and design are subject to modification, without notice, due to
improvements in technology.
