Part identification chart – ProForm PFBE1144.0 User Manual
Page 12
M8 x 70mm Button Bolt (25)
M6 Washer (35)
M8 Washer (34)
M4 Washer (23)
M8 Nylon Locknut (31)
M6 Nylon Locknut (32)
M4 x 16mm Self-
tapping Screw (28)
M8 x 25mm Flat Head Bolt (33)
M6 x 27mm Flat Head Bolt (24)
M6 x 16mm Screw (38)
M4 x 20mm Self-tapping
Screw (27)
M10 x 148mm Button Bolt (26)
M10 Nylon Locknut (30)
M6 Lock Washer (39)
PART IDENTIFICATION CHART
—Model No. PFBE1144.0
R0306A
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST in the center of this manual. Important: Some parts may have
been pre-assembled for shipping purposes. If a part is not in the parts bag, check to see if it has been
pre-attached.
