- 11 -
The hose located on the back of the
vacuum cleaner carries the dirt from the
nozzle up to the dust bag. If the hose
should become clogged:
➢ ➢ Unplug vacuum.
➢ ➢ Pull open suction inlet cover and
check for clogging.
➢ ➢ Remove lower plate.
➢ ➢ Remove hose from nozzle by lifting
straight up.
➢ ➢ Inspect hose end and clear any
obstructions.
➢ ➢ Reinstall hose and lower plate.
Hose
Manguera
Tuyau
Cover
(Suction Inlet)
Cubierta
(Abertura de
aspiracón)
Couvercle
(de l’entrée
d'aspiration)
+ Hose
Manguera
Tuyau
Removing Clogs
Voltaje Protector termal Extensión de cordón Herramientas
120 V c.a. (60Hz) Si 9,1 m (30 pi) Opcional
Power Thermal Protector Cord Length Tools
120V AC (60Hz) Yes 9.1 m (30 Ft.) Optional
Alimentation Protecteur thermique Longueur du cordon Accessoires
120 V c.a. (60Hz) Oui 9,1 m (30 pi) Optionnels
FEATURE CHART
Diagrama de características
Tableau des caractéristiques
- 34 -
