5
IMPEDANCECHART
Impedance is a measurement of the load placed on your receiver/amplifier by the
speakers. The load placed on your receiver/amplifier from thte control center will
vary depending on how many pairs of speakers you turn on at one time, and on which
speakers you turn on. The chart below shows the impedance for all possible combinations
of 8-ohm speakers.
PSS6
Speaker Sets On Impedance (Ω)
A, B, C, D, E or F 8
A+B, A+C, A+D
A+E, A+F, B+C
B+D, B+E, B+F
C+D, C+E, C+F, E+F
4
A+B+C, A+B+D, A+B+E
A+B+F, A+C+D, A+C+E
A+C+F, A+D+E, A+D+F
A+E+F, B+C+D, B+C+E
B+C+F, B+D+E, B+D+F
C+D+E, C+D+F, D+E+F
3.1
A+B+C+D, A+B+C+E
A+B+C+F, A+C+D+E
A+C+D+F, A+D+E+F
B+C+D+E, B+C+D+F
C+D+E+F 2.4
A+B+C+D+E+F 1.7
PSS4
Speaker Sets On Impedance (Ω)
A, B, C or D 8
A+B, A+C, A+D
B+C, B+D, C+D
4
A+B+C, A+B+D
A+C+D, B+C+D
3.1
A+B+C+D 2.4
