SD2320W | 10 | User's Guide
Monitor Specifications
Displays
Size 23” diagonal (583 mm)
Display type Active matrix color TFT LCD panel
Resolution 1920 x 1200 (WUXGA)
Display dot 1920 x (RGB) x 1200
Display area (mm) 495.36 x 306.60 (H x V)
Pixel pitch 0.258 mm
Brightness (2D mode, mirror raised) 250 cd/m 2 (typical), 200 cd/m 2 (minimum)
Brightness (Stereo/3D Mode) 80 cd/m 2 (typical, through the glasses)
Contrast ratio (2D mode, mirror raised) 800:1 (typical)
Response time 12 ms (3 ms rise, 9 ms fall)
Response time (gray to gray) 8 ms (typical)
Display color palette 16.7 million colors
Refresh rate 60 – 85 Hz (60 Hz recommended)
Power requirements, input voltage Single phase, 100 – 240 VAC (50/60 Hz)
Power requirements, input current 1.2 A maximum per monitor
Power supply Internal
Power consumption 110 W (max) per monitor, 220 W total
(4 W total standby)
Product approvals UL/CUL, CSA, TUV-GS, VCCI, FCC-B, TOC '99
MTBF 50,000 hours at 40°C
Video
Input signal Analog (VGA), Digital (24-pin DVI-D),
Composite, S-Video, USB 2.0
Input impedance 75 Ohm ± 2%
Sync input signal Digital TMDS, separate TTL compatible
horizontal and vertical synchronization
Polarity Positive, negative
Horizontal scan 30 – 85 kHz (Digital) / 30 – 95 kHz (Analog)
Vertical refresh 60 Hz (Digital) / 60 – 85 Hz (Analog)
Plug and Play
The unit supports the VESA DDC2B functions of Plug and Play.
