-3-
Figure #2
HCA-1500A Front Panel Drawing
Current Overload
Standby AC Line Normal
L R
Power
P o w e r S w i t c h P o w e r & S t a t u s I n d i c a t o r s
C u r r e n t O v e r l o a d I n d i c a t o r s
H C A - 1 5 0 0 A H i g h C u r r e n t M u l t i A m p l i f i e r
HCA - 1500A
High Current Power Amplifier
Parasound Products, Inc
San Francisco, CA U.S.A.
CAUTION:
TO PREVENT ELECTRIC SHOCK,
DO NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Power Consumption: 700 W
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
AC 120 V 60 Hz
Power
6.3 A Fuse WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD. DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
Mono Bridge
Stereo THX
Level
THX
Level
Speakers
Manufactured under license from LucasArts Entertainment
Company. U.S. and Foreign Patents pending. Lucasfilm THX Audio
and Home THX Symbols are Trademarks of LucasArts Entertainment
Company Lucasfilm is a Trademark of Lucasfilm Ltd.
CAUTION:
Speaker Impedance
4
Ω Minimum Stereo
8 Ω Minimum Bridged
L R
DC Trigger
GND +12 V Inputs
Loop Outputs
Speaker Connectors
Input Connectors,
Looping Output Connectors,
and Level Controls
AC Receptacle
+ 12 Vdc
Trigger Connector
Figure #1
HCA-1500A Front Panel Drawing
