Page 1
Model APS-510C
Owner’s Manual
5 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected.
Valet Switch manual override is pre-selected from the factory, however, the system
can be configured for "Custom Code" operation. Confirm the override mode selected on the
last page of this manual, and familiarize yourself with the selection on it's operation.
FEATURES :
 2 Five Button Programmable RF Transmitters (capable of accepting 4 transmitters)
 Five Channel Receiver
 Code Hopping Technology
 Selectable Manual Override Mode
 Remote Panic in all modes
 Protected Valet
 User Programmable Manual Override Code
 7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
 Intrusion Alert with Memory
 Audible Arm / Disarm / Defective Zone / Tamper Confirmation
 Instant Siren Activation
 Starter Disable
 Additional Engine Immobilizer Output (optional relay required)
 True Last Door Arming (hardwire only)
 Defective Zone By-Pass
 Hardwire or Voltage Sense Selectable
 Active or Passive Arming Selectable
 Programmable Auto Lock On / Off
 Programmable Auto Unlock On / Off
 Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
 Programmable Active or Passive Door Locks
 User Programmable Permanent Chirp Delete
 On Command RF Chirp Delete from Transmitter
 6 Tone Multi Tone Siren
 RF Inhibit with ignition on
 Parking Light Flasher
 Plug In Dual Stage Shock Sensor
OPTIONS:
 Remote Trunk Release ( must have electronic trunk release )
 Remote Keyless Entry ( must have power door locks )
 Multiple Vehicle Capable
 Remote Starter
 Remote Power Window Roll Up
 Remote Garage Door Interface
 Two Step Unlock Configurable
 Headlight Illumination During Arming, Disarming, Or Both
 Interior Illumination Upon Disarm
