SET-UP
1
Unfold the top portion of the
Sound Rocker until the backrest
is fl ush with the seat portion.
2
Place the Sound Rocker so
that the control panel is less than
11 ft./3.5 meters from the power
source.
11 FE
ET OR LESS
3
Connect the 12-volt AC power
adapter to the electrical outlet and
then to the power AC port on the
control panel.
4
Twist the volume knob to click
on the power.
5
Check the control panel to see
if it is lit up. Twist volume knob to
power off the Sound Rocker, then
proceed to the connection method
shown below for your audio/video
device.
CONNECTION METHODS
Video Game Console Connection
XBOX 360
TM
, PLAYSTATION 2
TM
, PLAYSTATION 3
TM
, GAMECUBE
TM
and others
There are four types of audio/video cables that come with video game consoles:
1.
1. Standard AV/RCA Cable
2. S-Video AV/RCA Cable
(red, white–audio; yellow–video)
(red, white–audio; yellow, black–S-video)
3.
3. High Defi nition AV/RCA Cable
4. Coaxial Connection
(
(red, white–audio; yellow, blue, red, green–video)
(single black cable)
)
(single black cable)
)
(single black cable)
)
(single black cable)
)
(single black cable)
)
(single black cable)
CAUTION:
Keep
fi ngers clear of the folding seam
when folding or unfolding the
rocker.
If you have this cable, you need to purchase the RCA
audio cable from the console manufacturer. Or, you can
connect the Pyramat through an intermediary audio
source such as a TV, DVD, VCR, etc. (see below).
