8. 9.
Do not apply pressure to combs. Do not touch razor
heads with hard objects as this may dent or damage
precision-made slotted combs.
Do not use razor if combs are damaged or broken. Facial
injury may occur.
Power Cord is not waterproof. Do not let cord get wet
and do not immerse cord in water.
After Each Use
1 Switch Razor OFF.
2 Press the Razor Head Release Button located on side
of Razor.
3 Flip open the Razor Head Assembly and clean the razor
heads and hair chamber by running under hot water.
Water from the tap should be on a hot setting BUT BE
CAREFUL TO TEST WATER FIRST SO AS NOT TO BURN
OR SCALD HANDS.
4 Close the Razor Head Assembly and shake off excess water.
5 Open Razor Head Assembly again and leave open
to air dry.
Replacing Lotion Cartridge
1 Slide down latch and lift back cover off razor. Remove
empty cartridge from razor and pull out the connector.
Insert the connector into a new cartridge.The connector
is secured when you hear it “click” into place.
2 Rinse out razor cartridge compartment with hot
water. Shake off excess water and slide new cartridge
with connector into the Razor. Close back cover.
Every 2 Months: Razor Heads
For consistently close and comfortable shaves, razor
heads should be cleaned in a degreasing liquid or
alcohol and then lubricated.
1 Turn razor OFF.
2 Press the Razor Head Release Button located on right
side of razor.
3 Remove the Razor Head Assembly and clean the razor
heads and hair chamber by running under hot water.
Be sure water is not too hot so as to cause burns or
scalding.
4 While holding Razor Head Assembly in one hand,
squeeze S-formation in center of retainer plate and lift
out frame.
5 Remove one cutter/comb at a time, out of frame.
IMPORTANT: Do NOT interchange the cutters and
combs.They are a matched set and if interchanged
may adversely affect shaving performance until cutters
reseat themselves.Therefore, remove, clean and replace
each set individually.
