Primo Water UL 900135 - Manual

Locate Dispenser
4. Place dispenser upright.
5. Locate dispenser on a hard and level surface in a cool shaded location
near a grounded wall outlet.
Notice: Do NOT plug in power cord yet.
6. Position dispenser so the back is at least 4 inches from wall and there are
at least 4 inches of clearance on both sides.
Assemble
3. Remove drip tray from door and place the grid on top.
4. Snap drip tray and grid assembly into door.
Install Water Bottle
10. Open dispenser door.
11. Place probe assembly on probe hanger.
12. Place fresh bottle outside of cabinet.
13. Remove entire plastic cap from top of bottle.
14. Clean outside of new bottle with a cloth.
15. Place probe into bottle.
16. Slide collar down until it clicks in place.
17. Push head down until tubes hit bottom of
bottle.
18. Slide bottle into cabinet and close door.
Provide Electricity
Plug cord into a properly grounded wall outlet.
At this time the pump will begin to move water
from the bottle to the hot and cold tanks. It will
take up to 12 minutes to fill the tanks for the first
time. During this period the pump will run
continuously. This is normal.
Primo Water Corporation, (“Vendor”) warrants to the original purchaser of this
dispenser, and to no other person, that if this dispenser is assembled and operated
in accordance with the printed instructions accompanying it, then for a period of
one (1) year from the date of purchase, all parts in such dispenser shall be free from
defects in material and workmanship. Vendor may require reasonable proof of your
date of purchase from an authorized retailer or distributor. Therefore, you should
retain your sales slip or invoice. The Limited Warranty shall be limited to repair or
replacement of parts, which prove defective under normal use and service and
which Vendor shall determine in its reasonable discretion upon examination to be
defective. Before returning any parts, you should contact Vendor’s Customer
Service Department using the contact information listed below. If Vendor confirms,
after examination, a defect covered by this Limited Warranty in any returned part,
and if Vendor approves claim, Vendor will replace such defective part without
charge. If you return defective parts, transportation charges must be prepaid by
you. Vendor will return replacement parts to original purchaser, freight or postage
prepaid.
The Limited Warranty does not cover any failures or operating difficulties due to
accident, abuse, misuse, alteration, misapplication, improper installation or
improper maintenance or service by you or any third party, or failure to perform
normal and routine maintenance on the dispenser, as set out in the User’s Manual.
In addition, the Limited Warranty does not cover damages to the finish, such as
scratches, dents, discoloration or rust after purchase.
The Limited Warranty is in lieu of all other express warranties. Vendor disclaims all
warranties for products that are purchased from seller other than authorized
retailers or distributors. AFTER THE PERIOD OF THE ONE (1) YEAR EXPRESS
WARRANTY, VENDOR DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. FURTHER, VENDOR SHALL HAVE NO LIABILITY
WHATSOEVER TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT,
PUNITIVE, INCIDENTAL, OR CONSEQUENTAL DAMAGES. Vendor assumes no
responsibility for any defects caused by third parties. This Limited Warranty gives
the purchaser specific legal rights; a purchaser may have other rights depending
upon where he or she lives. Some jurisdictions do not allow exclusion or limitation
of special, incidental or consequential damages, or limitations on how long a
warranty lasts, so the above exclusion and limitations may not apply to you.
Primo Water Corporation
104 Cambridge Plaza Drive
Winston-Salem, NC 27104
866-429-7566
www.PrimoWater.com
LIMITED WARRANTY SAFETY PRECAUTIONS
To reduce risk of injury and property damage, user must read this
entire guide before assembling, installing & operating dispenser.
Failure to execute the instructions in this manual can cause
personal injury or property damage.
This product dispenses water at very high temperatures. Failure to
use properly can cause personal injury.
When operating this dispenser, always exercise basic safety
precautions, including the following:
 Prior to use, this dispenser must be properly assembled and installed in
accordance with this manual.
 This dispenser is intended for water dispensing only. Do NOT use other liquids.
Do NOT use for other purposes. Never use any other liquid in the dispenser
other than known and microbiologically safe bottled water.
 For indoor use only. Keep water dispenser in a dry place away from direct
sunlight. Do NOT use outdoors.
 Install and use only on a hard, flat and level surface.
 Do NOT place dispenser into an enclosed space or cabinet.
 Do NOT operate dispenser in the presence of explosive fumes.
 Position back of dispenser no closer than 4 inches from wall and permit free
airflow between wall and dispenser. There must be at least 4 inches clearance
on the sides of the dispenser to permit airflow.
 Use only properly grounded outlets.
 Do not use an extension cord with your water dispenser.
 Always grasp plug and pull straight out from outlet. Never unplug by pulling on
power cord.
 Do NOT use dispenser if cord becomes frayed or otherwise damaged.
 To protect against electric shock, do NOT immerse cord, plug, or any other part
of dispenser in water or other liquids.
 Ensure dispenser is unplugged prior to cleaning.
 Never allow children to dispense hot water without proper and direct
supervision. Unplug unit to prevent unsupervised use by children.
 Service should be performed only by a certified technician. Please contact us at
866-429-7566 for assistance.
Bottom Loading
Water Dispenser
Model # 900135
TO REDUCE THE RISK OF INJURY
AND PROPERTY DAMAGE, USER
MUST READ THIS MANUAL
BEFORE ASSEMBLING, INSTALLING
& OPERATING DISPENSER.
SAVE THIS MANUAL
FOR FUTURE USE
PN O-057 © 2010 Primo Water Corporation
FEATURES & FUNCTIONS
GETTING STARTED
Function Lights – Green light below ON icon indicates the dispenser is
plugged in. Green light below snowflake indicates the dispenser is cooling
water. Green light below wavy lines indicates the dispenser is heating water.
Blinking red light below the bottle icon indicates the bottle is empty.
Cold Pushbutton Control – Depress control to dispense. Release to stop.
Cool Pushbutton Control – Depress control to dispense. Release to stop.
Hot Pushbutton Control with Child Safety Feature – Slide red button away
from you and depress control to dispense. Release to stop.
Bottle Support – Helps align sports bottles and glasses with spout to
eliminate spills.
Spout – Hot, cool and cold water comes out here.
LED Nightlight – Located behind bottle support. Helps in low light situations.
Probe Assembly – Located inside cabinet. Connects to bottle to allow water
to be pumped into hot and cold tanks.
Probe Hanger – Located inside door at top. To keep probe assembly clean
when changing bottles, rest it here.
Drip Tray & Grid – Dishwasher safe. Snaps in and out. Position glass, cup or
pot over center hole in grid to avoid spills.
Water Bottle – Not included. Uses 3, 4 or 5 gallon bottles. Go to
www.PrimoWater.com to find Primo Water at a store near you.
Energy Saver Switches – Located on back. Switch red control to off to stop
heating. Switch green control to off to stop cooling.
Nightlight Switch – Located on back. Allows you to choose to have the
nightlight ON or OFF.
Dispensing Cool Water
1. Position bottle, glass, pitcher or cooking pot below spout.
2. Depress cool water control downward to start cool water flow.
3. Release control once desired fill level is achieved.
Dispensing Hot Water (185°F – 210°F)
After setup, hot water will be available in 15-20 minutes.
4. Position bottle, glass, pitcher or cooking pot below spout.
5. Slide red button away from you and depress hot water control downward
to start hot water flow.
6. Release control once desired fill level is achieved.
Changing Bottles
A flashing red light on your function lights alerts you when your bottle is
empty. Replace the bottle as soon as possible.
Notice: Do not dispense hot, cool or cold water if the red light is flashing as
you could empty the tanks and cause the dispenser to overheat.
8. Open dispenser door.
9. Slide empty bottle out of cabinet.
10. Remove probe assembly from empty bottle. Place probe assembly on
probe hanger.
11. Set empty bottle aside.
12. Place fresh bottle outside of cabinet. Remove entire plastic cap from top of
bottle. Clean outside of new bottle with a cloth.
13. Place probe into bottle. Slide collar down until it clicks in place. Push head
down until tubes hit bottom of bottle.
14. Slide bottle into cabinet and close door.
Water is leaking.
 Unplug dispenser, remove bottle and call 866-429-7566 for assistance.
No water is coming from the spout.
 Make sure the bottle is not empty. If empty, replace it.
 Make sure to completely depress the pushbutton controls.
Cold water is not cold.
 It takes up to one hour after setup to dispense cold water.
 Make sure the power cord is properly connected to a working outlet.
 Make sure the back of the dispenser is at least 4 inches from a wall and
there is free airflow on all 4 sides of the dispenser.
 Make sure green power switch on back of dispenser is ON.
 If water still isn’t cold, please call 866-429-7566 for assistance.
Hot water is not hot.
 It takes 15-20 minutes after setup to dispense hot water.
 Make sure the power cord is properly connected to a working outlet.
 Make sure red power switch on back of dispenser is ON.
Nightlight Isn’t Working
 Make sure the power cord is properly connected to a working outlet.
 Make sure nightlight power switch on back of dispenser is ON.
Dispenser Is Noisy
 Make sure the dispenser is positioned on a level surface.
TROUBLESHOOTING
Please visit www.PrimoWater.com for more useful information, instructional videos, tips and special offers.
IMPORTANT: Do Not Return Dispenser to Store. If you have questions or issues please contact 1-866-429-7566 for expert assistance.
Activate Heating & Cooling
Notice: This unit will not dispense hot or cold water until the switches are
activated.
To activate, push top side of power switches in to start heating and cooling
water.
- If you do not want to heat water, push bottom side of red switch in.
- If you do not want to cool water, push bottom side of green switch in.
Activate Nightlight
Push top side of blue power switch in to turn light on. Push bottom side in to
turn light off.
Register Online
While you wait for the water to get hot and cold, please register your
dispenser. This will be helpful should you need customer service assistance in
the future.
Go to www.PrimoWater.com and click on Customer Care.
…………………………………………………………………………………………………………………………..
DISPENSING WATER
This unit has been tested and sanitized prior to packing and shipping. During
transit dust and odors can accumulate in the tank and lines. Dispense and
dispose at least one quart of water prior to drinking any water.
Dispensing Cold Water (37°F – 50°F)
After setup, it will take up to 1 hour to get water to maximum cold
temperature. During this time the compressor could run continuously. This is
normal.
4. Position bottle, glass, pitcher or cooking pot below spout.
5. Depress cold water control downward to start cold water flow.
6. Release control once desired fill level is achieved.
Head
Collar
5 Gallon Bottle
3 Gallon Bottle
Head
Collar
