16”
Front: 9”
Rear: 8” solid
Limited
Up to 5 mph
Intelligent Braking
(electronic, regenerative disc brakes)
4.25”
26.25”
Length: 47” (without front riggings)
Width: 30.375” 2
(2) 4-pole, in-line, mid-wheel drive motors
Two 12 volt, deep cycle (gel cell or AGM)
Up to 15 miles
8A, off-board (standard)
100A, PG Remote Plus controller
100A, Q-Logic controller
650 lbs. maximum (user weight)
176 lbs.
53.5 lbs. (each)
Lifetime limited warranty on frame
2-year warranty on electronics
18-month warranty on drive motor
DRIvE WHEELS
OMNI-CASTERS:
SUSPENSION
MAxIMUM SPEED 1
BRAkES
GROUND CLEARANCE 4
TURNING RADIUS 4
OvERALL SIzE 4
DRIvE TRAIN
BATTERIES
RANGE PER CHARGE 1
BATTERy CHARGER
AvAILABLE
ELECTRONICS
WEIGHT CAPACITy
BASE WEIGHT
BATTERy WEIGHT
WARRANTy
.
Heavy-duty, in-line dual motors, patented
mid-wheel drive design .
Reinforced frame and heavy-duty springs on the
front anti-tip wheels .
Accepts larger seating systems for maximum comfort .
8A, off-board battery charger .
16” drive wheels and 9” caster wheels for maximum
stability .
Top speed up to 5 mph .
Easy front-access dual freewheel levers .
Lifetime limited warranty on frame
.
70° heavy-duty leg rests .
Lap belt .
Rear basket .
Oxygen tank holder .
Cane holder .
Crutch holder .
Walker holder .
Safety flag .
Heavy-duty Synergy ® Seat .
(4) NF-22, 55AH batteries (38 lbs. each)
for extended range (20 miles)
Specifications Features
Options
Shroud Colors
Candy
Apple Red
viper
Blue
Onyx
Black
Champagne
Q1650-7-26-07
Quantum 1650 (Code: k0899)
Quantum 1650 3SPvHD - SS (Code: k0860) 3
Code Coverage
FOOTNOTES:
1) Range and speed vary with user weight, terrain type,
battery charge, battery condition and tire pressure.
2) Overall width is increased when using a seat with a
width greater than 26”.
3) 500 lbs. weight capacity
4) Due to manufacturing tolerances and continual product
improvement, this specification can be subject to variance
of + or – 3 %.
(US) 866-800-2002
(Canada) 888-570-1113
www.quantumrehab.com
