Philips Semiconductors
Product specification
TOPFET high side switch
BUK205-50Y
SMD version of BUK201-50Y
Fig.16. Typical input threshold voltages.
V
IG
= f(T
j
); conditions V
BG
= 13 V, I
L
= 80 mA
Fig.17. Typical input clamping voltage.
V
IG
= f(T
j
); conditions I
I
= 200
µ
A, V
BG
= 13 V
Fig.18. Typical status characteristic, T
j
= 25 ˚C.
I
S
= f(V
SG
); conditions V
IG
= V
BG
= 0 V
Fig.19. Typical status leakage current.
I
S
= f(T
j
); conditions V
SG
= 5 V, V
IG
= V
BG
= 0 V
Fig.20. Typical status low characteristic, T
j
= 25 ˚C.
I
S
= f(V
SG
); conditions V
IG
= 5 V, V
BG
= 13 V, I
L
= 0 A
Fig.21. Typical status low voltage, V
SG
= f(T
j
).
conditions I
S
= 50
µ
A, V
IG
= 5 V, V
BG
= 13 V, I
L
= 0 A
-60
-20
20
60
100
140
180
Tj / C
VIG / V
BUK205-50Y
3.0
2.5
2.0
1.5
1.0
VIG(ON)
VIG(OFF)
-60
-20
20
60
100
140
180
Tj / C
IS
BUK205-50Y
10 uA
1 uA
100 nA
10 nA
-60
-20
20
60
100
140
180
Tj / C
VIG / V
BUK205-50Y
8.0
7.5
7.0
6.5
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
VSG / V
IS / uA
BUK205-50Y
500
400
300
200
100
0
0
2
4
6
8
10
VSG / V
IS / mA
BUK205-50Y
20
15
10
5
0
-60
-20
20
60
100
140
180
Tj / C
VSG / V
BUK205-50Y
1
0.8
0.6
0.4
0.2
0
July 1996
8
Rev 1.000
