ProForm STRIDE SELECT PFEL3926.0 - Manual (Page 6)

6
1.
Identify the Rear Stabilizer (4). While another person
lifts the rear of the Frame (1), attach the Rear
Stabilizer to the Frame with two M10 x 75mm Carriage
Bolts (34) and two M10 Nylon Locknuts (29).
4
34
29
29
1
2. See the inset drawing. Remove the two M10 x 45mm
Button Bolts (33) and the packing tubes from the front
of the Frame (1). Remove the rubber band from the
Lower Wire Harness (87). Discard the rubber band
and the packing tubes.
Attach a Wheel (32) to the Front Stabilizer (3) with an
M10 x 45mm Button Bolt (33) and an M10 Nylon
Locknut (29). Do not overtighten the Nylon
Locknut; the Wheel should turn freely.
Attach the other Wheel (32) to the Front Stabilizer
(3) in the same way.
Press two Stabilizer Endcaps (35) onto the Front
Stabilizer (3).
1
33
2
Packing Tube
Packing
Tube
1
87
29
33
32
35
3
32
35
To make assembly easier, read the information
on page 5 before you begin assembling the
elliptical exerciser.
