REFERENCE
ENGLISH
ENGLISH
VIDEO SECTION
Video system PAL625/50, PAL525/60, NTSC
Composite video output
Output level 1 Vp-p (75 )
Terminal For Southeast Asia, Thailand, the Middle East, South
Africa, Saudi Arabia, Kuwait, Australia aand N.Z.
Pin jack (1 system)
For Continental Europe Scart jack (1 system)
For Continental Europe
S-video output
Y output level 1 Vp-p (75
)
C output level PAL; 0.3 Vp-p (75
)
NTSC; 0.286 Vp-p (75 )
Terminal Scart jack (1 system)
Component video output (NTSC: 480p/480i, PAL: 576p/576i)
Y output level 1 Vp-p (75 )
P B output level 0.7 Vp-p (75
)
P R output level 0.7 Vp-p (75 )
Terminal Pin jack (Y: green, P B : blue, P R : red) (1 system)
For Continental Europe
RGB video output
R output level 0.7 Vp-p (75
)
G output level 0.7 Vp-p (75 )
B output level 0.7 Vp-p (75 )
Terminal Scart jack (1 system)
HDMI AV output
Terminal Type A connector (19 pin)
This unit supports “HDAVI Control 2” function.
SPEAKER SECTION
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
Front speakers SB-HF550
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 
Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 76 Hz to 25 kHz (–16 dB)
89 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 252 mm x 1123 mm x 235 mm
Mass 3.7 k g
For Continental Europe, Australia and N.Z.
Surround speakers SB-HS550
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 
Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 95 Hz to 25 kHz (–16 dB)
120 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 92 mm x 142 mm x 95 mm
Mass 0.6 k g
Center speakers SB-HC550
Type 2 way, 2 speaker system (Bass refl ex)
Speaker unit(s) Impedance 6 
1. Full range 6.5 cm Cone type
2. Full range 6.5 cm Cone type
Input power (IEC) 250 W * (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 80 Hz to 25 kHz (–16 dB)
96 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 270 mm x 94 mm x 95 mm
Mass 1.3 k g
Subwoofer SB-HW550
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 6 
Woofer 16 cm Cone type
Input power (IEC) 250 W (Max)
Output sound pressure 81 dB/W (1.0 m)
Frequency range 31 Hz to 220 Hz (–16 dB)
37 Hz to 180 Hz (–10 dB)
Dimensions (W x H x D) 153 mm x 415 mm x 257 mm
Mass 3.6 k g
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
Surround speakers SB-HS850
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 
Full range 6.5 cm Cone type
Input power (IEC) 125 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 76 Hz to 25 kHz (–16 dB)
89 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 252 mm x 1123 mm x 235 mm
Mass 3.7 k g
For Australia and N.Z.
Front speakers SB-HF850
Type 2 way, 2 speaker system (Bass refl ex)
Speaker unit(s) Impedance 6 
1. Full range 6.5 cm Cone type
2. Full range 6.5 cm Cone type
Input power (IEC) 250 W * (Max)
Output sound pressure 83 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 79 Hz to 25 kHz (–16 dB)
95 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 252 mm x 1123 mm x 235 mm
Mass 3.8 k g
For Australia and N.Z.
Surround speakers SB-HS851
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 4 
Full range 6.5 cm Cone type
Input power (IEC) 100 W * (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 76 Hz to 25 kHz (–16 dB)
89 Hz to 22 kHz (–10 dB)
Dimensions (W x H x D) 252 mm x 1123 mm x 235 mm
Mass 3.7 k g
WIRELESS TRANSMITTER AND RECEIVER
Power supply
For Southeast Asia, Thailand, the Middle East,
South Africa, Saudi Arabia and Kuwait
AC 110 to 240 V, 50/60 Hz
For Australia and N.Z. AC 230 to 240 V, 50 Hz
Power consumption
Tx (SH-FX65T) 1.5 W
Rx (SE-FX65) 43 W
Dimensions (W x H x D)
Tx (SH-FX65T) 65 mm x 52 mm x 8.6 mm
Rx (SE-FX65) 165 mm x 90 mm x 164 mm
Mass Tx (SH-FX65T) 0.02 k g
Rx (SE-FX65) 0.655 k g
Wireless module
Frequency range 2.4000 to 2.4835 GHz
No. of channels 3
RMS output power
Surround Ch 125 W per channel (3 ), 1 kHz, 10% THD
Total RMS power 250 W
DIN output power
Surround Ch 70 W per channel (3 ), 1 kHz, 1% THD
Total DIN power 140 W
Speaker Jack impedance indication 3  to 6 
Operating temperature range +5 °C to +35 °C (+41 °F to +95 °F)
Operating humidity range 5 % to 90 % RH (no condensation)
For Australia and N.Z.
RMS output power
Surround Ch 100 W per channel (4 ), 1 kHz, 10% THD
Total RMS power 200 W
DIN output power
Surround Ch 70 W per channel (4 ), 1 kHz, 1% THD
Total DIN power 140 W
Speaker Jack impedance indication 3  to 6 
Power consumption in off mode approx. 0.3 W
*8 Power output of the wireless receiver amplifi er SE-FX65
