(Refer to WIRING CONNECTION DIAGRAM)
4 TROUBLESHOOTING GUIDE
4.1. CHECK POINTS FOR ELECTRICAL PARTS.
< TROUBLE > < CHECK > < REMEDY >
Does not operate. NO Replace battery
→ If no less than 24V DC is available across the (+) and (-) → pack.
terminals after charging the rated charging time (45min.),
the battery pack is OK.
NOTE: The battery pack is sold separately as an optional
accessory. See the nearest sales dealer for
details. The battery pack has a limited life.
The pack should be replaced if;
- after being charged for the rated charging
time the battery voltage is less than 24V DC
or the usable time is extremely short.
- the battery leaks. Check battery for leaks
and terminals for corrosion.
↓OK
NO Repair contacts or
MAIN UNIT AND BATTERY PACK.> → replace switch
Check for proper terminal contacts or if there is any foreign assembly.
substances around the battery terminals of battery holder.
↓OK
NO Replace motor
The motor normally operates with its white (+) and gray (-) → rotor and brush
lead wires connected to 24V DC. assembly.
Does not speed- NO Replace switch &
control but switch → Even if FET block is defective, it can not be replaced → FET block.
trigger works individually. Replace whole switch block.
properly.
