WARNING

We are not responsible for any personal injury or product damage
due to mishandling, incorrect mounting, incorrect assembly or
incorrect use of this product.

The supplied wall mounting hardware is not for use on steel stud walls or cold

cinder block walls. If you are uncertain about the nature of your wall, please consult a
qualified contractor. If the hardware you required is not included please contact your
local hardware store.

Note:

15 degree
viewing angle

eyelevel

Fig 2a

Step 2:

mount to wall

First, determine the height of stand
The best height of stand is parallel to eyelevel of a person who sitting on a couch.
Normally, the horizontal distance of eyelevel is about 4’ from ground level.
The following two conditions are for determining the perfect height of stand:
1)

the distance between wall and couch(Fig 2a).

the distance of eyelevel from ground level plus the distance measured from

eyelevel of a person sitting on couch with viewing angle of 15 (Fig 2a).

For example:
1)

the distance of ‘a’ is 5’-7’, the distance of ‘b’ is about 1’

the distance of ‘a’ is 8’-13’, the distance of ‘b’ is about 3’

the distance of ‘a’ is 14’-17’, the distance of ‘b’ is about 4’

The perfect height of stand centre will be anywhere within b, where you feel
comfortable for viewing.

Attach

Step 2: Attach mount to wall

Check your TV manual to confirm the diameter of bolt to be used or choose an
appropriate bolt according to size, height and position of the holes on your TV. See
pages 4-5 of these instructions for examples.

For correct installing, make sure that hook of ever y bracket must facing down. Use
selected bolts, spacers and washers for installing bracket at the back of display.
Adjust two brackets to equal heights and level. Once aligned, tightly secure the
bolts.

the

UP side on the top As shown in Fig.1b.

Note

Step 1: Attach bracket to TV

If your display hole’s vertical distance> 400mm, you need to use the lengthen
bracket on both brackets(2,3).Lengthen bracket(4,5) installation:
According your display hole's distance to choose the bracket hole's.
Install the Lengthen bracket(4,5) directly to the both brackets(2,3) by using
M6x50mm(9) bolts M6 washers(8) and M6 nuts(7), As shown in Fig 1a.

Step 1: Attach bracket to TV

Caution :

This Product LCD /Plasma Wall Mount Bracket is intended for use only

with the maximum weights indicated .See apparatus instructions .Use with products
heavier than the maximum weights indicated may result in instability causing possible
injury .

Caution :

Fig 1a

Fig 1b
