Parasound NEW CLASSIC 2100 - Manual (Page 19)

19
MODEL 2100 SPECIFICATIONS AND SETUP NOTES
Audio Specifications
Frequency Response
10 Hz – 100 kHz, +0/–3 dB
THD Distortion
< 0.008% at 20 Hz
S/N Ratio
> 105 dB, input shorted, IHF A-weighted
> 95 dB, input shorted, unweighted
Crosstalk
> 75 dB at 20 kHz
Input Impedance
30k ohms
Output Impedance
< 60 ohms
Input Sensitivity
250 mV for 1 V output
Total Gain: 12 db
Maximum Output: 6.5 V
AC Power Requirement
110-250 V, 50 - 60 Hz
Voltage is automatically selected
5 watts standby; 10 watts when turned on
General Information
Dimensions
Width: 17.25” (437 mm)
Depth: 14.5” (369 mm)
Height, with feet: 4.25” (108 mm)
Height, without feet: 3.5” (89 mm)
Weight: Net: 13 lbs. (5.9 kg)
Shipping: 20 lbs. (9.1 kg)
Rack Mount Accessory
RMK22 (May be purchased separately)
Note: Specifications and features subject to change or improvement without notice.
© 2007 Parasound Products, Inc. Crestron, AMX, Control4, Niles and Elan are registered trademarks. Rev. 0.9
Notes:
