VQT4H46 (ENG)
12
1 Lens
2 Zoom lever
3 Shutter button
4 [˜] (Burst Mode) button
5 Self-timer indicator
AF Assist Lamp
6 Mode dial
7 Flash
8 Lens barrel
9 Diopter adjustment dial
10 Speaker
• Be careful not to cover the speaker with
your finger. Doing so may make sound
difficult to hear.
11 Shoulder strap eyelet
12 [HDMI] socket
13 [AV OUT/DIGITAL] socket
14 Viewfinder
15 Stereo microphone
16 Camera ON/OFF switch
17 Motion picture button
18 Power lamp
19 [FOCUS] button
20 Rear dial
21 [DISP.] button
22 [MENU/SET] button
23 Cursor buttons
24 [Q.MENU] button/
[
] (Delete/Cancel) button
25 [(] (Playback) button
26 [EVF/LCD] button
27 LCD monitor
28 Tripod mount
• A tripod with a screw length of 5.5 mm
(0.22 inch) or more may damage this
unit if attached.
29 Release lever
30 Card/Battery door
(DMC-FZ200)
31
Flash open lever
• To close, push the top of the flash cover
until it clicks.
32 [MIC/REMOTE] socket
33 Focus selector switch
34 Side lever
35 Hot shoe
36 [Fn1] button
37 [Fn3] button
38 [AF/AE LOCK] button/[Fn2] button
39 DC coupler cover
• When using an AC adaptor, ensure that
the Panasonic DC coupler
(DMW-DCC8: optional) and AC adaptor
(DMW-AC8PP: optional) are used.
• Always use a genuine Panasonic AC
adaptor (DMW-AC8PP: optional).
(DMC-FZ60)
40
Flash open button
41 [AF/AF#/MF] button
42 [AF/AE LOCK] button/[Fn1] button
43 DC coupler cover
• When using an AC adaptor, ensure that
the Panasonic DC coupler
(DMW-DCC6: optional) and AC adaptor
(DMW-AC8PP: optional) are used.
• Always use a genuine Panasonic AC
adaptor (DMW-AC8PP: optional).
