A compact and economical
solution for small to medium-sized conference rooms.
Ideal for smaller conference spaces, the new entry-level Polycom VSX 5000 set-top system delivers
market-leading video and audio quality at an affordable price. A real space-saver, it sits conveniently on top
of TVs, high-resolution plasma screens, or LCD displays. You can easily add a peripheral (document camera,
or VCR/DVD), dual monitors, and audio-only callers through ISDN or the SoundStation VTX 1000 ® . In fact
the VSX 5000 gives you multiple ways of dialing conference attendees and delivering various types of
content (for example, pictures, presentations, audio files). Connection options include IP (H.323 and SIP)
and ISDN dialling, so you can utilise the VSX 5000 in a variety of conference environments.
The VSX 5000 is also well-suited for educational resource rooms where smaller groups of students meet
with a remote educational specialist, and remote medical clinics that deliver specialist care to patients
hundreds of kilometers from home.
The VSX 5000 includes features and benefits such as a user interface in 15 languages, multiple ways to
add content, and dual monitor emulation for single display solutions. Choose either a VGA display or a
TV as your main display, whichever suits your conferencing environment. The ISDN option enables you to
add ISDN conferencing capability as well, and the dual monitor option allows you to show people in one
display and shared content in the other display.
Add simplicity and reduce conference table clutter by taking advantage of the Polycom SoundStation VTX
1000 integration with the VSX 5000. This integration gives users the ability to dial, hang up and mute a
video conference right from the conference phone. Since the SoundStation VTX 1000 acts as the stereo
microphone as well as a standalone conference phone, there is no need for any other microphone on
the table. Plus, dedicated stereo audio outputs enable easy implementation of Polycom's StereoSurround ™
technology, which separates multiple voices with conversational stereo.
In today's Internet driven world, the ability to conduct real time communication and collaboration has
become critical to an organisation's survival. As the market leader in voice, video, data and Web solutions,
our award-winning conference technology makes it easy for people to interact and maximise productivity –
over any network, in numerous environments, anywhere around the globe. That's why more organisations
worldwide prefer using Polycom conferencing solutions. Because when people work together, great things
happen.
Polycom ® VSX ™ 5000
Video conferencing system offering excellent
price performance and flexibility
Benefits
Superior, natural sound – Polycom
StereoSurround™ delivers crisp, natural
voice clarity - even when multiple parties
are speaking simultaneously – by using
dual channel, Siren™ 14 technology
Outstanding video – Premium quality
video at any bandwidth with smooth
natural motion and sharp, clear images.
Employs standard-based H.264
compression and Pro-Motion™ video
for optimal video performance
Multimedia made easy – Show high-res
images, movies or presentations in your
meetings while in a video call. And, you
can share PC content cable-free using
Polycom's unique People+Content™ IP
technology
Reliability – Integrated electronic
Pan-Tilt-Zoom (PTZ) camera has fewer
moving parts and therefore offers more
reliability, while offering functionality
similar to mechanical PTZ cameras
Secure Conferencing – Ensuring your
video conferences are secure and private
through embedded encryption via secure
video, audio and data traffic; secure
web management, protection against
unauthorised access (web, telnet, FTP).
Complete solution packages –
Combine the VSX 5000 with any of
Polycom's attractive furniture display
options to create a total meeting
room solution
The Polycom Solution – Everything you
need to deploy and manage a complete
video conferencing network with Polycom
ReadiManager SE 200, Polycom Global
Management System™, Polycom
PathNavigator™, Polycom Conference
Suite™ and the Polycom MGC™
Polycom VSX 5000 Specifications
Part No. 3726-17347-002 Rev. 06/06
H.323, SIP and H.320 compliant
VSX 5000 Bundled Packages
• VSX 5000 VTX: VSX 5000 system with
SoundStation VTX 1000 instead of the
microphone array
• VSX 5400 Presenter: VSX 5000 system,
Visual Concert™ VSX, People+Content IP
• VSX 5400 Presenter VTX: VSX 5000 system,
Visual Concert VSX, People+Content IP,
SoundStation VTX 1000 instead of
microphone array
Bandwidth
• Maximum Data Rate IP: 768Kbps
• Maximum Data Rate ISDN: 512Kbps
Video Standards & Protocols
• H.261
• H.263+ Annexes: F, I, J, L, N, T
• H.263++ Annexes: W (receive-only)
• H.264
Frame Rates (Point-to-Point)
• Intelligently selects frame rate for best
performance video
• 30 fps from 56 kbps up to 768 Kbps
Video Inputs:
• Main Camera + 1
Connectors
• Integrated main camera
• 1 x S-Video; 4-pin mini DIN Document camera,
VCR/DVD or second camera)
• RS-232 Data Port: 1 x 8-pin mini DIN
- Control port for custom integration with
remote devices such as Crestron ® and AMX ®
control systems
- Connectivity for closed captioning
teletype device
- Communication port for transmission
of serial data (i.e. medical devices) over
ISDN or IP calls
Video Outputs: 3 Connectors
• 2 x S-Video 4-pin mini DIN
• 1 x VGA HD15
Video Formats
• NTSC/PAL
• Graphics: XGA, SVGA, VGA
Integrated Main Camera
• Noiseless, ultra-fast action electronic
pan/tilt/zoom (PTZ)
• 65° field of view
• Electronic Tilt Range: +/- 24° (Up/Down)
• Electronic Pan Range: +/- 42.5° (Left/Right)
• 85° Total Field of View
• 2x Zoom
• Lens F#: 2.8mm
• Focal length: 4.9mm
• Fixed focus
• Automatic white balance
• Camera presets – local and far-end (up to 99)
• Standards-based, far-end camera control (FECC)
People Video Resolution
• 4SIF (704 x 480), 4CIF (704 x 576) *2nd video only
• SIF (352 x 240), CIF (352 x 288)
• QSIF (176 x 120), QCIF (176 x 144)
• Choice of 4:3 or 16:9 display aspect ratios
Content Video Resolution
• XGA (1024 x 768), SVGA (800 x 600),
VGA (640 x 480) for graphic displays
• People video support for 4CIF and 4SIF on
second VGA display
• Up to 4CIF for NTSC/PAL displays
Audio Standards & Protocols
• Polycom StereoSurround ready
• 14 kHz bandwidth with Polycom Siren
™ 14
(G.722.1 Annex C)
• 7 kHz bandwidth with G.722, G.722.1
• 3.4 kHz bandwidth with G.711, G.728, G.729A
Audio Features
• Audio only add-in over ISDN
• Full-duplex digital audio
• Instant Adaptation Echo Cancellation
• Automatic Gain Control (AGC) – Voice activated
• Automatic Noise Suppression (ANS)
• Audio Mixer (Mic, VCR, line-in)
• Real-time audio level meter
• Microphone and VCR input audio mixing
• Ability to talk over VCR audio
Audio Inputs: 3 Connectors
• 1 x Conference Link
- Supports 1 microphone
- Supports SoundStation VTX 1000
conference phone
• 1 x RCA input for stereo or mono input from
external mixer
Audio Outputs: 2 Connectors
• Main Audio Out (RCA Stereo)
Polycom Digital Tabletop Microphone
• 360° voice pick up
• Three cardioid elements per microphone
• Flotation feet reduce transmission of
tabletop noise
• Integrated mute button
• Optional Polycom Ceiling Microphone Array
is available
Other ITU-Supported Standards
• H.221 communications
• H.224/H.281 far-end camera control
• H.323 Annex Q far-end camera control
• H.225, H.245, H.241, H.331
• H.239 People+Content™
• H.231 in multipoint calls
• H.243 MCU password
• H.233, H.234, H.235V3 encryption standards
• H.460 NAT/firewall traversal
• Bonding, Mode 1
SIP Support (Sessions Initiation Protocol)
• Register and authenticate with:
- Microsoft LCS
- Nortel MCS
- Standards-based SIP servers
• FECC
• H.261, H.263, H.264
• G.711, G.722, G.722.1, G.728, G.729A, Siren 14
(G.722.1 Annex C)
• Microsoft LCS contact list support
• Microsoft LCS presence support
• Interoperable with Microsoft Office
Communicator
Network Interfaces Supported
• Single 10/100 Ethernet port
(10Mbps/100Mbps/Auto)
• Optional ISDN BRI (Basic Rate Interface) Module
• Optional wireless LAN support via customer
provided wireless bridge
Network Features
• Integration with Cisco Systems ® CallManager
Version 4.0
• Down speeding over IP and ISDN
• Audio & Video Error Concealment over IP, ISDN
and mixed calls
• IP address conflict warning
• Maximum call length digital timer
• Auto SPID detection and line number
configuration
• MGC™ Click&View™ for individual screen
layouts
• Polycom OneDial™ intelligent call management
attempts call on preferred network (IP or ISDN)
and automatically rolls over to secondary
network if needed
• Polycom PathNavigator™ support for easy call
placement and network cost optimization
• TCP/IP, UDP/IP, RTP, DNS, WINS, DHCP, ARP,
HTTP, FTP, Telnet
• Chair control through API command or Integrated
Web Interface.
• Software Upgradeable Inverse Multiplexer (IMUX)
Conference on Demand
• Initiates unscheduled MGC calls from
the endpoint
• Utilises Polycom Office™ (PathNavigator
and MGC)
• Auto selects an external bridge
• Dials all participants simultaneously
Security
• Account validation number entry
• SNMP trap notification of all failed login
attempts from HTTP, FTP or Telnet
• FIPS 140-2 (Pre-validation List)
- Secure web (HTTPS)
- Secure Telnet, FTP
- Security mode
• Secure password authentication
• Administrator password – in-room and
remote access
• Dial-in meeting password
• Encrypted password for VSX Web access
• Ability to disable remote interfaces (FTP,
Telnet, HTTP, SNMP)
• Auto-Answer (On/Off)
• Allow access to user settings (On/Off)
Embedded Encryption
• Advanced Encryption Standard (AES)
• FIPS 197 validated by National Institute of
Standards & Technology (NIST) certified agency
• 128-bit key length
• AES software encryption on ISDN and IP
• Standards-based H.235V3 (IP)
• Standards-based H.233/H.234 (ISDN/Serial)
• Automatic key generation and exchange
• Supported in People+Content
User Interface
• User-friendly graphical interface
• Customisable home screen and color themes
• Kiosk mode with scrolling marquee
• User-selectable camera icons and ring tones
• Speed Dial List on home page
• Persistent Preview (Far-site PIP) on all screens
• Picture In Picture (PIP) (On/Off, Moveable)
• Dual Monitor Emulation
• Calendar and Conference scheduling
• Alert Signal on home page
• Do Not Disturb (On/Off)
• Closed captioning support
Directory Services
• 4,000 number global directory
• 1,000+ number local directory
• Speed dial list displaying video buddy list
• Live address book with Polycom Global Directory
Services automatically and quickly updates
directory with address changes or new endpoints
• Polycom Global Directory Services integrates
with Active Directory/LDAP
• Directory Server backup in the event Polycom
Global Directory is not accessible
• Automatic ISDN localisation of calls
• Closed captioning support
System Management
• SNMP for enterprise management
• Baseline mode setting for legacy system
interoperability
• Diagnostics and software upgrades via PC, LAN
• Integrated VSX Web management tool
• Web Director: Remote administrator video
monitoring and control from VSX Web
(enabled/disabled from endpoint for security)
• Out-of-box setup from VSX Web
• Place a call from VSX Web
• Language independence between set-top
interface and VSX Web
• System configuration from VSX Web
• Recent Calls Log – last 99 incoming and
outgoing calls
• Call Detail Record (CDR) – Reports all incoming
and outgoing calls along with call statistics
• CDR Feature On/Off
• Downloadable CDR data for processing requires
no external management system
• Account number validation at call initiation
integrated with Polycom Global Management™
System for billing purposes
• Administrator-configurable dialing speeds
iPriority ™ – Quality of Service Features
• Video Error Concealment
• Audio Error Concealment
• Universal Plug and Play (UPnP)
• IP Precedence (ToS)
- Configurable video/audio/FECC service value
• DiffServ (DSCP) (COS)
• RSVP
• Dynamic Bandwidth Allocation
• Proactive Network Monitoring
• Adjustable Packet Size
• NAT/firewall traversal (H.460)
• Packet and jitter control
• Network Address Translation (NAT) support
• Automatic NAT discovery
• Asymmetric speed control
• Alternate Gatekeeper Support
• TCP/UDP fixed-port firewall support
• Lip synchronisation
• Echo cancellation
• Echo suppression
• Auto gatekeeper discovery
• Automatic gateway dialing profiles
• Specify outbound call routing for gateway/ ISDN
Collaboration Solutions
• Visual Concert VSX (Audio and video input from
PC or Macintosh ® ) (Optional)
- 1 x audio input for laptop
- 1 x VGA output for projector
- 3 x 10/100 Ethernet hub
- Content Input: 1280 x 1024, 60 Hz
- Content Output: Up to 1024 x 768
• People+Content IP (Optional)
- Show content from laptop/PC over IP network
connection
- Content shown in native resolution
- Supports Windows
® 2000 and Windows XP
• QSX (Optional)
- Connect to Visual Concert to show content
from laptop/PC
- Content shown in native resolution
- Up to 10 voice participants can view content
being shared
• Adjustable bandwidth for content
- 10% Content, 90% People
- 50% Content, 50% People
- 90% Content, 10% People
• Web Streaming in and out of a call, RTP-based,
suitable with QuickTime ® Players
Furniture solutions
• Media Center with audio system
• Media Center
• Media Cart
• Video Cart
• Wall Mount Solution
Language Support (15 languages)
• Chinese (Simplified), Chinese (Traditional),
English (American), English (British), French,
German, Hungarian, Italian, Japanese, Korean,
Norwegian, Polish, Portuguese, Russian, Spanish
• Translated items include:
- Documentation (not Hungarian/Polish)
- User interface
- Audio dialing confirmation
- VSX web
- Remote control (not Hungarian/Polish)
Electrical
• Auto sensing power supply
• Operating voltage/power 90-260 VAC,
47-63 Hz/80 watts
• Max 75 VA@115v60Hz, 85 VA@220v50Hz
• Max Heat Dissipation: 273 BTU/hour
Environmental Specifications
• Operating Temperature: 0-40° C
• Operating Humidity: 15-80%
• Non-Operating Temperature: -40-70° C
• Non-Operating Humidity (Non-condensing):
10-90%
Physical Characteristics
• Video Base Unit (W/H/D):
300.5mm/133.26mm/254.5mm
11.83"/5.25"/10.02",
• Video Base Unit Weight: 1.94Kg/4.4 lbs
Warranty
• One-year return to factory parts and labour
• 90-day Software Warranty
©2006 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo and SoundStation VTX 1000 are registered trademarks and VSX, StereoSurround, Siren, MGC, Click&View, Polycom PathNavigator, Polycom OneDial,
Visual Concert, Polycom Office, Global Management System, People+Content, Polycom Conference Suite and iPriority are trademarks of Polycom, Inc.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
Polycom EMEA Headquarters: 270 Bath Road, Slough, Berkshire SL1 4DX, United Kingdom, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom (France) Sarl: Tour Areva, 31st Floor, 1 place de la Coupole, 92084 la Defense, Paris, France, (T) +33 141 321 999, (F) +33 141 321 998
Polycom (Germany) GmbH: Am S ö ldnermoos 17, 85399 Hallbergmoos, Germany, (T) +49 (0)811-9994 - 100, (F) +49 (0)811-9994 - 200
Polycom (Italy) S.r.l. Via Rivoltana 2/d, 20090 Segrate, MI, Italy, (T) +39 02 753 99 210, (F) +39 02 75 39 92 49
Polycom (Spain) S.A. Lopez de Hoyos 35 - 1°, 28002 Madrid, Spain, (T) +34 91 7459973 , (F) +34 91 7459999
Polycom Headquarters: 4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
www.polycom.com
