3 www.pridemobility.com INFINFB2045/Rev A/12-04-06
B
ASIC
T
ROUBLESHOOTING
I
NSTRUCTIONS
: J
ET
3 U
LTRA
What if the left red battery condition meter LED on the GC is flashing?
! This indicates that battery voltage is very low and the batteiries should be charged immediately.
What if the battery condition meter LEDs light up left-to-right one at a time in a step sequence?
! This indicates that the GC is in lock mode. The GC is equipped with a lock mode feature that prevents
unintended use of the power chair. If the GC is in lock mode, deflect the joystick full forward until it beeps,
deflect the joystick full rearward until it beeps, then release the joystick. The controller will emit one long beep
indicating a return to normal operation.
What if the battery condition meter LEDs ripple left-to-right and the power chair will not drive?
! Determine if the battery charger is connected to the power base. When the battery charger is connected to
the power base, an internal charger inhibit feature keeps the power chair from driving.
! Determine if the charger harness fuse has blown. A blown charger fuse can cause the charger inhibit to
activate.
VSI DIAGNOSTIC FLASH CODES
# OF LEDS CODE CAUSE POSSIBLE SOLUTION
One red LED 1 Low battery voltage Charge batteries
Two red LEDs 2 Left motor open Make sure left motor is plugged into controller.
Three red LEDs 3 Left motor wiring fault Contact your authorized Pride Provider.
Three red LEDs 4 Right motor open Make sure right motor is plugged into controller.
One yellow LED
Three red LEDs
5 Right motor wiring fault Contact your authorized Pride Provider.
Two yellow LEDs
Three red LEDs
6 Inhibit active Contact your authorized Pride Provider.
Three yellow LEDs
Three red LEDs
7 Joystick error Contact your authorized Pride Provider.
Four yellow LEDs
Three red LEDs
8 Controller error Contact your authorized Pride Provider.
Four yellow LEDs
One green LED
Three red LEDs
9 Brake fault Make sure both motors are plugged into controller.
Four yellow LEDs
Two green LEDs
Three red LEDs
10 High battery voltage Contact your authorized Pride Provider.
Four yellow LEDs
Three green LEDs
