39 Wrangler www.pridemobility.com
A P P E N D I X I - S P E C I F I C A T I O N S
Model Numbers PMV600
Overall Length 2 See figure 19.
Overall Width 2 See figure 19.
Tires Type: Pneumatic Front: 6 in. x 13 in.; Rear: 6 in. x 13 in. (15 x 33 cm)
Weight Capacity 400 lbs. (181.4 kg) maximum
Battery Type 3 (not included) Two 12V, 100AH
Horsepower 3.0 hp (peak)
Charger Onboard 5-amp charger
Speed (Max) 1 Variable up to 10 mph (60% reverse)
Maximum Allowable Incline 5° (8.7%)
Range 1 Up to 30-35 miles per charge with 100Ah batteries
Turning Radius 2 See figure 19.
Body Colors Candy Apple Red, Viper Blue
Seating Style: High-back with headrest and sliders
Dimensions: See figure 19.
Seat Cover Material: Vinyl; Black, Gray, Tan, or Brown
Armrests: Match seat cover material
User adjustable seat height from ground: 27.75-31.75 in. (70.49-80.65 cm)
User adjustable seat height from deck: See figure 19.
Brakes Electronic regenerative braking and electromechanical disc brake
Rear Wheel Drive 2-24 VDC motors
Wheels Aluminum alloy wheels in Black
Tiller Type 4-position adjustable
Weight Total weight with batteries: w/two 12V, 100Ah batteries: 345 lbs. (156.4 kg)
Total weight without batteries: seat and rear shroud: 216 lbs. (97.98 kg)
Component Breakdown:
Rear Plastic Shroud: 3.5 lbs. (1.59 kg)
Seat: 37 lbs. (16.78 kg)
Batteries: 63 lbs. (28.58 kg) each
Ground Clearance 2 See figure 19.
1 Varies with user weight, terrain type, battery amp-hour (Ah), battery charge, battery condition, and tire condition. This
specification can be subject to a variance of (+ or -) 10%.
2 Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of
(+ or - ) 3%.
3 AGM or Gel-Cell type required. See IV. “Batteries and Charging.”
NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 Series
EN12184 standards. All specifications subject to change without notice.
