Poulan 190944 - Manual (Page 37)

37
TRACTOR - - MODEL NUMBER PD185H42ST (PD185H42STB)
DECALS
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
KEY PART
NO. NO. DESCRIPTION
6
2
1
5,8
4,10
3,9
11
7
WHEELS AND TIRES
KEY PART
NO. NO. DESCRIPTION KEY PART
NO. NO. DESCRIPTION
10
3
16
9
1 59192 Cap Valve Tire
2 65139 Stem Valve
3 106222X Tire F T 15 x 6 0 - 6 Service
4 59904 Tube Front (Service Item Only)
5 106732X421 Rim Asm 6" front Service
6 278H Fitting Grease (Front Wheel Only)
7 9040H Bearing Flange (Front Wheel nly)
8 106108X421 Rim Asm 8" rear Service
9 122082X Tire R T 20 x 10-8 Service
10 7152J Tube Rear (Service Item Only)
11 104757X421 Cap Axle Blk 1 50 x 1 00
- - 144334 Sealant, Tire ( 10 oz. Tube)
8
20
14
5
1 157032 Decal Oper
3 186164 Decal Hood LH
4 189289 Decal Side Panel Logo
5 189288 Decal HP Engine
6 170563 Decal Warning, Keep Hand Away
7 190928 Decal Replacement Parts
8 179128 Decal Deck "B" 42"
9 172740 Decal Fender Logo
10 157140 Decal Fender Danger E/F
11 172743 Decal Ins Strg Whl
12 173587 Decal Fend Refl ector Rh
13 173589 Decal Fend Refl ector Lh
1
14 160396 Decal V-Belt Schematic
16 186163 Decal Hood Rh
20 145005 Decal Bat Dan/Psn
- - 179768X428 Pad Footrest LH
- - 179769X428 Pad Footrest RH
- - 178392 Decal Chass Disconnect LTH 2000
- - 138311 Decal Handle Lft Height Adjust
- - 190944 Manual Owner's (English)
- - 190945 Manual Owner's (French)
7
11
4
4
6
12
13
